Retgersite

Ni(SO4) · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Rtg
Discovered
1948
Also known as
  • Retgersiet

Where it forms, where it's found

Geological setting

A secondary mineral in the oxidization zone of nickel-bearing rocks. Forms at temperatures between 31.5°C and 53.5°C. Also at temperatures at least as low as 0°C when there is an excess of free H2SO4.

Type locality
Ragra Mine
  1. Huayllay District
  2. Pasco Province
  3. Pasco
  4. Peru

-10.8610°, -76.5722°

65recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Emerald green with blue tinge · pale green in transmitted light.
Streak
Greenish-white
Tenacity
brittle
Cleavage
Perfect

On (001), perfect; traces on (110) in crushed grains under magnification.

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
2.04 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.4873 – 1.5109
Surface relief
Low
Principal indices
nω 1.5109 · nε 1.4873
Michel-Lévy diagramhighlighted lineδ = 0.0236
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]236 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation236 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
#167
Cell parameters
a = 6.78 Å · c = 18.28 Å
Morphology

Artificial crystals thick tabular (001) grading to short prismatic [001]. Fibrous crusts or veinlets, fibers elongated [001]; twisted spire- or horn-like tufts. Single crystals rare. Type material prismatic on [001] showing the forms (001), (110), (011), (012) and (112).

Type-locality form

Poorly formed, bluish green crystals, to 1 mm in length, encrusting a black coke-like mass of patronite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
60.87%
28NiNickelNickel158.69358.693
22.33%
16SSulfurSulfur132.06032.060
12.20%
1HHydrogenHydrogen121.00812.096
4.60%
Total262.839100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Retgersiet

In other languages

French
Retgersite
German
Retgersit
Italian
Retgersite
Russian
Ретгерцит · Ретгерцит (минерал)

Classification

Strunz
10th ed.

7.CB.30

  • 7SulfatesClass
  • 7.CSulfates (selenates, etc.) without additional anions, with H2ODivision
  • 7.CBWith only medium-sized cationsGroup
  • 7.CB.30RetgersiteSpecies
Dana
8th ed.

29.06.09.01

  • 29Hydrated Acid and Normal SulfatesClass
  • 29.06AXO4·xH2OType
  • 29.06.09— unnamed intermediate level —Group
  • 29.06.09.01RetgersiteSpecies
CIM

25.12.5

  • 25SulphatesClass
  • 25.12Sulphates of Co and NiGroup
  • 25.12.5RetgersiteSpecies

Group, growth & confusion

Often grow together
2 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1823Brooke (1823) Annals of Philosophy, London: 22: 437 (on artificial crystals).
  2. 1828Mitscherlich (1828) Annalen der Physik, Halle, Leipzig: 12: 146.
  3. 1855Rammelsberg (1855): 92.
  4. 1863Scacchi (1863) Reale accademia delle scienze fisische e matematiche, Naples, Att.: 1(11) (artificial material).
  5. 1872Topsøe (1872) Arch. sc. phys. nat. Genève: [2]: 45: 223.
