Sapphirine

Mg4(Mg3Al9)O4[Si3Al9O36]
IMA status
  • Approved
  • Grandfathered
IMA symbol
Spr
Discovered
1809
Also known as
  • Blauer Diamantspath
  • Saphirin

Where it forms, where it's found

Geological setting

In high-temperature metamorphic rocks or xenoliths with abundant aluminium and magnesium and low silicon. May occur as a primary magmatic mineral in subsilicic rocks.

Type locality
Fiskenæsset old harbour
  1. Qeqertarsuatsiaat area
  2. Nuuk
  3. Sermersooq
  4. Greenland

63.0872°, -50.6781°

124recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Light blue · blue-gray · green · greenish gray · rarely yellow-brown or pink
Streak
colourless
Cleavage
Poor/Indistinct

(100), (001), and (010)

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.4 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 51 – 69° · 2V calc = 78 – 88°
Refractive index
1.701 – 1.734
Surface relief
High
Principal indices
nα 1.701 – 1.729 · nβ 1.703 – 1.732 · nγ 1.705 – 1.734
Pleochroism
Visible

X = pinkish buff, yellowish, light smoky brown, colourless Y = sky-blue, sapphire-blue, greenish blue Z = dark sky-blue, dark sapphire-blue

Dispersion
r < v
Michel-Lévy diagramhighlighted lineδ = 0.0045
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]45 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation45 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 11.27 Å · b = 14.4 Å · c = 9.93 Å
Cell angles
β = 125.5 °
Ratio a:b:c
1 : 1.278 : 0.881
Unit cell volume
1312 ų
Z
4
Morphology

Crystals tabular (010), slightly elongated [001] at times. Usually as disseminated grains or aggregations of grains.

Twinning

Polysynthetic twinning on one, or possibly two, laws is observed in polished sections when 1A polytype is present. Repeated on (010); uncommon (Handbook of Mineralogy).

Comment

Unit cell from Moore (1969), for 2M polytype. 2M polytype is commonest. 1A, 3A, 4M and 5A also known.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4015.999639.960
46.37%
13AlAluminiumAluminium1826.982485.676
35.19%
12MgMagnesiumMagnesium724.305170.135
12.33%
14SiSiliconSilicon328.08584.255
6.11%
Total1380.026100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Blauer Diamantspath
  • Saphirin

In other languages

French
Saphirine · sapphirine
German
Saphirin · Sapphirin
Spanish
Safirina · Sapphirina · Zafirina
Italian
Saffirina · Sapphirine
Japanese
サフィリン · 疑サファイア石
Chinese
假蓝宝石
Russian
Сапфирин

Classification

Strunz
10th ed.

9.DH.45

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DHInosilicates with 4-periodic single chains, Si4O12Group
  • 9.DH.45SapphirineSpecies
Dana
8th ed.

69.02.1b.01

  • 69Inosilicates Chains with Side Branches or LoopsClass
  • 69.02Chains with Side Branches or Loops with P>2Type
  • 69.02.1b— unnamed intermediate level —Group
  • 69.02.1b.01SapphirineSpecies
CIM

16.7.2

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.7Aluminosilicates of MgGroup
  • 16.7.2SapphirineSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1819Stromeyer, F. (1819) Summary of meeting 16 descember 1819 [Analyse einiger Grönlandischen, von Prof. Gisecke erhaltenen Fossilien] Göttingsche Gelehrte Anziegen 3: 1993-2003
  2. 1819Stromeyer, F. (1819) Analyse einiger von dem Prof. von Giesecke in Grönland entdeckten Fossilien, 2. Saphirin von Fiskenaes oder Kikertarsoeitsiak, Annalen der Physik und Chemie, Vol. 63, p 374
  3. 1819Giesecke (1819) Stromeyer, Göttingen gel. Anz.: 1994.
  4. 1821Giesecke (1821) Untersuch. Misch. Mineralk.: 1: 391.
  5. 1847Hausmann (1847) 427.
