Grandidierite

MgAl3O2(BO3)(SiO4)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gdd
Discovered
1902
Also known as
  • Grandidieriet

Where it forms, where it's found

Geological setting

Pegmatite cross-cuts migmatitic high-grade granulite-facies metapelite gneisses and leptynites

Accessory mineral from aluminous boron rich rocks that underwent thermal and regionally metamorposed (low-pressure conditions); found in aplites, pegmatites; gneisses; xenoliths

Type locality
Cap Andrahomana
  1. Andranobory
  2. Taolagnaro District
  3. Anosy
  4. Madagascar

-25.1994°, 46.6324°

31recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Bluish green · greenish blue

Increasingly greener with greater Fe content; colourless to blue or green in thin section

Cleavage
Perfect

more perfect (100), and (010)

Density
2.98 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 24 – 32° · 2V calc = 32°
Refractive index
1.59 – 1.639
Surface relief
Moderate
Principal indices
nα 1.590 – 1.602 · nβ 1.618 – 1.636 · nγ 1.623 – 1.639
Pleochroism
Visible

X= beep blue to blue green Y= colorless Z= light greenish blue to deep green

Dispersion
very strong (r < v)
Notes

Orientation: X=a, Y=b, Z=c; absorption: Z>X>Y

Michel-Lévy diagramhighlighted lineδ = 0.0350
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]350 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation350 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 10.335(2) Å · b = 10.978(2) Å · c = 5.760(2) Å
Ratio a:b:c
1 : 1.062 : 0.557
Z
4
Morphology

Anhedral elongated individuals to 8cm; usually strongly corroded

Type-locality form

Bluish green masses up to several centimeters across, in quartz

Comment

Pbnm space group

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
49.97%
13AlAluminiumAluminium326.98280.946
28.09%
14SiSiliconSilicon128.08528.085
9.75%
12MgMagnesiumMagnesium124.30524.305
8.44%
5BBoronBoron110.81010.810
3.75%
Total288.137100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mn
  • Na
  • K

Synonyms

  • Grandidieriet

In other languages

French
grandidiérite
German
Grandidierit
Italian
Grandidierite
Portuguese
grandidierite
Japanese
グランディディエライト
Chinese
硅硼镁铝矿

Classification

Strunz
10th ed.

9.AJ.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AJNesosilicates with BO3 triangles and/or B[4], Be[4] tetrahedra, cornersharing with SiO4Group
  • 9.AJ.05GrandidieriteSpecies
Dana
8th ed.

54.01.01.01

  • 54Nesosilicates Borosilicates and Some BeryllosilicatesClass
  • 54.01Borosilicates and Some Beryllosilicates with (BO3)Type
  • 54.01.01Grandidierite GroupGroup
  • 54.01.01.01GrandidieriteSpecies
CIM

17.5.49

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.49GrandidieriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1902Lacroix, Alfred (1902) Note préliminaire sur une nouvelle espèce minérale. Bulletin de la Société française de Minéralogie, 25 (4-5) 85-86
  2. 1922Lacroix, Alfred (1922) Minéralogie de Madagascar, Tome I. Géologie-Minéralogie descriptive. Augustin Challamel. 624 pp.
  3. 1965McKie, Duncan (1965) The magnesium aluminium borosilicates: kornerupine and grandidierite. Mineralogical Magazine and Journal of the Mineralogical Society, 34 (268). 346-357 doi:10.1180/minmag.1965.034.268.29DOI: 10.1180/minmag.1965.034.268.29
  4. 1968Stephenson, D. A., Moore, P. B. (1968) The crystal structure of grandidierite, (Mg,Fe)Al3SiBO9. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 24 (11) 1518-1522 doi:10.1107/s0567740868004577DOI: 10.1107/s0567740868004577
  5. 1975Zav'yalova, I.V., Vartanova, N.S., Arkhipenko, D.K., Grigor'yeva, T.N., and Solotchina, E.P. (1975) A find of grandidierite in western Transbaikaliya. Dokl. Akad. Nauk. SSSR 213, 140-142.
