Schwertmannite

Fe3+16O16(OH)9.6(SO4)3.2 · 10H2O
IMA status
  • Approved
IMA symbol
Swm
Discovered
1990
IMA approved
1990
Also known as
  • IMA1990-006
  • Schwertmanniet

Where it forms, where it's found

Geological setting

Precipitate from acid, sulphate-rich waters.

Type locality
Pyhäsalmi Mine
  1. Pyhäjärvi
  2. North Ostrobothnia
  3. Finland

63.6833°, 25.9833°

46recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Earthy
Transparency
Opaque
Colour
Brownish yellow
Streak
Yellow
Density
3.88 g/cm³

Crystallography

Crystal system
Tetragonal
Cell parameters
a = 10.66 Å · c = 6.04 Å
Morphology

Tiny (2-4 nm thick, 60-90 nm long), fibrous crystals arranged in the form of pin-cushion-like aggregates.

Type-locality form

Ochreous. Poorly crystalline, yellowish brown, with a fibrous morphology under the electron microscope.

Comment

Poorly crystalline

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron1655.845893.520
49.63%
8OOxygenOxygen48.415.999774.352
43.01%
16SSulfurSulfur3.232.060102.592
5.70%
1HHydrogenHydrogen29.61.00829.837
1.66%
Total1800.300100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1990-006
  • Schwertmanniet

In other languages

German
IMA 1990-006 · Oxyhydroxysulphat · Schwertmannit
Spanish
Schwertmannita
Italian
Schwertmannite

Classification

Strunz
10th ed.

7.DE.15

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DEWith only medium-sized cations; unclassifiedGroup
  • 7.DE.15SchwertmanniteSpecies
Dana
8th ed.

06.04.10.01

  • 06Hydroxides and Oxides Containing HydroxylClass
  • 06.04MiscellaneousType
  • 06.04.10— unnamed intermediate level —Group
  • 06.04.10.01SchwertmanniteSpecies

Group, growth & confusion

Often grow together
4 minerals

Literature, links & citation

Citations
  1. 1994Bigham, J.M., Carlson, L., Murad, E. (1994) Schwertmannite, a new iron oxyhydroxysulfate from Pyhasalmi, Finland, and other localities. Mineralogical Magazine: 58: 641-664.
  2. 1995European Journal of Mineralogy (1995) 7: 547-552.
  3. 1995Jambor, John L., Pertsev, Nikolai N., Roberts, Andrew C. (1995) New Mineral Names. American Mineralogist, 80 (7-8). 845-850
  4. 1996Schwertmann, Udo; Fojt, Bohuslav (1996) Schwertmannit - ein neues Mineral und seine Geschichte [Schwertmannite - a new mineral and its history]. Lapis, 21 (5). 33-34
  5. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
