Shulamitite

Ca3TiFe3+AlO8
IMA status
  • Approved
IMA symbol
Sla
Discovered
2011
IMA approved
2011
Also known as
  • IMA2011-016
  • Shulamitiet
  • Unnamed (Ca-Ti-Fe-Al Oxide)

Where it forms, where it's found

Geological setting

Major to accessory mineral in high-temperature metacarbonate larnite rocks.

Type locality
Hatrurim Basin
  1. Tamar Regional Council
  2. Beersheba Subdistrict
  3. Southern District
  4. Israel

31.2017°, 35.2833°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Reddish brown
Streak
Light brown
Cleavage
Distinct/Good

Good on (010) and imperfect on (001) and (100)

Fracture
Irregular/Uneven
Density
3.84 g/cm³

Optical

Pleochroism
Visible

In thin section from reddish brown to yellow-brown, under reflected light from grey to light grey.

Optical colour
Grey to light grey
Anisotropism
Weak
Bireflectance
Weak
Internal reflections
Yellow-brown
Tropism
Anisotropic
Reflectance R%
(14.6, 13.4) 400, (13.6, 12.5) 420, (13.3, 12.2) 440, (12.9, 11.9) 460, (12.5, 11.6) 480, (12.6, 11.6) 500, (12.3, 11.4) 520, (12.2, 11.4) 540, (13.1, 12.2) 560, (12.5, 11.7) 580, (12.2, 11.6) 600, (12.2, 11.5) 620, (12.3, 11.5) 640, (12.3, 11.4) 660, (11.9, 11.3) 680, (11.7, 11.2) 700
Reflected-light panel
12.6 %anisotropic · dual curve
Specimen sRGB 132, 92, 50
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak
Anisotropism
Weak
Reflected colour
Grey to light grey
Internal reflections
Yellow-brown

Crystallography

Crystal system
Orthorhombic
Space group
Pmma
Cell parameters
a = 5.4200(6) Å · b = 11.064(1) Å · c = 5.5383(7) Å
Ratio a:b:c
1 : 2.041 : 1.022
Unit cell volume
332.12 ų
Z
2
Morphology

Xenomorphic or subhedral grains and their intergrowths. Individual prismatic platelets and star-like aggregates. Prismatic crystals have following forms: (100), (010), and (001), rhombic prisms are minor.

Twinning

The simple (in 90°) and complex (in 90°, 45° and 60°) twinning is common.

Type-locality form

Reddish brown subhedral grains or prismatic platelets up to 0.2 mm and intergrowths up to 0.5 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
33.78%
20CaCalciumCalcium340.078120.234
31.73%
26FeIronIron155.84555.845
14.74%
22TiTitaniumTitanium147.86747.867
12.63%
13AlAluminiumAluminium126.98226.982
7.12%
Total378.920100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2011-016
  • Shulamitiet
  • Unnamed (Ca-Ti-Fe-Al Oxide)

In other languages

German
IMA 2011-016 · Shulamitit
Italian
shulamitite

Classification

Strunz
10th ed.

4.AC.10

  • 4OxidesClass
  • 4.AMetal: Oxygen = 2:1 and 1:1Division
  • 4.ACM:O = 1:1 (and up to 1:1.25); with large cations (+- smaller ones)Group
  • 4.AC.10ShulamititeSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 1976Grenier, J.-C., Darriet, J., Pouchard, M., Hagenmuller, P. (1976) Mise en evidence d'une nouvelle famille de phases de type perovskite lacunaire ordonnee de formule A3M3O8 (AMO2,67) Materials Research Bulletin, 11 (10) 1219-1225 doi:10.1016/0025-5408(76)90024-6DOI: 10.1016/0025-5408(76)90024-6
  2. 1989Rodríguez-Carvajal, J., Vallet-Regí, M., González-Calbert, J.M. (1989) Perovskite threefold superlattices: A structure determination of the A3M3O8 phase. Materials Research Bulletin, 24 (4) 423-430 doi:10.1016/0025-5408(89)90023-8DOI: 10.1016/0025-5408(89)90023-8
  3. 1994Prasanna, T.R.S., Navrotsky, A. (1994) Energetics in the brownmillerite-perovskite pseudobinary Ca2Fe2O5-CaTiO3. Journal of Materials Research, 9 (12) 3121-3124 doi:10.1557/jmr.1994.3121DOI: 10.1557/jmr.1994.3121
  4. 2008Sharygin, V.V., Sokol, E.V., Vapnik, Ye. (2008) Minerals of the pseudobinary perovskite-brownmillerite series from combustion metamorphic larnite rocks of the Hatrurim Formation (Israel) Russian Geology and Geophysics, 49 (10) 709-726 doi:10.1016/j.rgg.2008.03.001DOI: 10.1016/j.rgg.2008.03.001
  5. 2011Kolitsch, U. & Brandstätter, F. (2011): 1709) Srebrodolskit und die Phase Ca3Ti(Fe,Al)2O8 in einem Ca-reichen Xenolith aus dem Basaltbruch Klöch, Bad Radkersburg, Steiermark. Pp. 174-175 in Niedermayr, G. et al. (2011): Neue Mineralfunde aus Österreich LX. Carinthia II, 201./121., 135-186.
