Stibarsen

SbAs
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sbr
Discovered
1941
Also known as
  • Allemontite
  • Allemontite II
  • Arsenoestibio
  • +2 more

Where it forms, where it's found

Geological setting

Hydrothermal veins, pegmatites

Type locality
Varuträsk
  1. Skellefteå
  2. Västerbotten County
  3. Sweden

64.8008°, 20.7411°

54recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
White · reddish gray · tarnishes gray
Streak
Gray
Cleavage
Perfect

in one direction

Density
5.8 g/cm³

Optical

Tropism
Anisotropic
Reflectance R%
(64.8,67.8) 400, (65.0,68.0) 420, (65.2,68.2) 440, (64.8,67.9) 460, (64.0,67.2) 480, (63.0,66.8) 500, (62.3,66.6) 520, (61.6,66.3) 540, (61.2,66.0) 560, (60.8,65.9) 580, (60.5,65.8) 600, (60.3,65.7) 620, (60.1,65.8) 640, (60.0,66.2) 660, (59.8,66.3) 680, (59.6,66.4) 700
Reflected-light panel
62.1 %anisotropic · dual curve
Specimen sRGB 255, 191, 111
White reference100 % reflector under same lamp
R₁ R₂
Mode

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 4.045 Å · c = 10.961 Å
Z
6
Morphology

Indistinct crystals, reniform, mamillary, curved lamellar, finely granular.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony1121.760121.760
61.91%
33AsArsenicArsenic174.92274.922
38.09%
Total196.682100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Bi
  • Fe
  • S

Synonyms

  • Allemontite
  • Allemontite II
  • Arsenoestibio
  • Stibarsen (Synonym)
  • Stibarsenic

In other languages

French
Stibarsen
German
Stibarsen
Spanish
Estibarsenio
Italian
Stibarsenico
Japanese
ヒ素アンチモン
Arabic
ستيبارسين

Classification

Strunz
10th ed.

1.CA.05

  • 1ElementsClass
  • 1.CMetalloids and NonmetalsDivision
  • 1.CAArsenic group elementsGroup
  • 1.CA.05StibarsenSpecies
Dana
8th ed.

01.03.01.03

  • 01Native Elements and AlloysClass
  • 01.03Semi-metals and non-metalsType
  • 01.03.01Arsenic groupGroup
  • 01.03.01.03StibarsenSpecies
CIM

1.42

  • 1Elements and Alloys (including the arsenides, antimonides and bismuthides of Cu, Ag and Au)Class
  • 1.42— unnamed intermediate level —Group
  • 1.42StibarsenSpecies

Group, growth & confusion

In the same group
3 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1936Holmes, Ralph J. (1936) An X-ray Study of Allemontite. American Mineralogist, 21 (3) 202-203
  2. 1937Quensel, Percy, Ahlborg, Knut, Westgren, Arne (1937) Minerals of the Varuträsk Pegmatite. I. Allemontite: With an X-ray Analysis of the Mineral and of other Arsenic-Antimony Alloys. Geologiska Föreningen i Stockholm Förhandlingar, 59 (2) 135-144 doi:10.1080/11035893709444937DOI: 10.1080/11035893709444937
  3. 1938Trzebiatkowski, W., Bryjak, E. (1938): Röntgenanalyse des Systems Arsen-Antimon. Zeitschrift für Anorganische und Allgemeine Chemie 238, 255-267.
  4. 1941Wretblad, P. E. (1941) Minerals of the Varuträsk Pegmatite. XX. Die Allemontite und das System As-Sb. Geologiska Föreningen i Stockholm Förhandlingar, 63 (1). 19-48 doi:10.1080/11035894109452808DOI: 10.1080/11035894109452808
  5. 1974Fleischer, Michael (1974) New mineral names. American Mineralogist, 59 (11-12). 1330-1332
