Stilbite-Na

Na9(Si27Al9)O72 · 28H2O
IMA status
  • Approved
IMA symbol
Stb-Na
Also known as
  • Stilbiet-Na

Where it forms, where it's found

Type locality
Capo di Pula (Capo Pula
  1. Nora)
  2. Pula
  3. Metropolitan City of Cagliari
  4. Sardinia
  5. Italy

38.9844°, 9.0161°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · Pearly
Transparency
Transparent · Translucent
Colour
White · colourless · red · light yellow · light to dark brown · cream
Streak
White
Cleavage
Perfect

Perfect on the (010)

Fracture
Conchoidal
Density
2.1 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 22 – 79° · 2V calc = 76 – 78°
Refractive index
1.479 – 1.505
Surface relief
Low
Principal indices
nα 1.479 – 1.492 · nβ 1.485 – 1.5 · nγ 1.489 – 1.505
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0115
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]115 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation115 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 13.63 Å · b = 18.17 Å · c = 11.31 Å
Cell angles
β = 129.166 °
Ratio a:b:c
1 : 1.333 : 0.830
Z
1
Comment

Pseudo-orthorhombic F-centred (as is stilbite-Ca).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen10015.9991599.900
55.86%
14SiSiliconSilicon2728.085758.295
26.47%
13AlAluminiumAluminium926.982242.838
8.48%
11NaSodiumSodium922.990206.910
7.22%
1HHydrogenHydrogen561.00856.448
1.97%
Total2864.391100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Stilbiet-Na

In other languages

German
Stilbit-Na
Italian
stilbite-Na

Classification

Strunz
10th ed.

9.GE.10

  • 9SilicatesClass
  • 9.GTektosilicates with zeolitic H2O; zeolite familyDivision
  • 9.GEChains of T10O20 TetrahedraGroup
  • 9.GE.10Stilbite-NaSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1970Slaughter, Maynard (1970) Crystal structure of stilbite. American Mineralogist, 55 (3-4) 387-397
  2. 1971Galli, E. (1971) Refinement of the crystal structure of stilbite. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 27 (4) 833-841 doi:10.1107/s056774087100298xDOI: 10.1107/s056774087100298x
  3. 1978Passaglia, Elio, Galli, Ermanno, Leoni, Leonardo, Rossi, Giuseppe (1978) The crystal chemistry of stilbites and stellerites. Bulletin de Minéralogie, 101 (3) 368-375 doi:10.3406/bulmi.1978.7200DOI: 10.3406/bulmi.1978.7200
  4. 1997Coombs, Douglas S., Alberti, Alberto, Armbruster, Thomas, Artioli, Gilberto, Colella, Carmine, Galli, Ermanno, Grice, Joel D., Liebau, Friedrich, Mandarino, Joseph A., Minato, Hideo, et al. (1997) Recommended nomenclature for zeolite minerals; report of the Subcommittee on Zeolites of the International Mineralogical Association, Commission on New Minerals and Mineral Names. The Canadian Mineralogist, 35 (6). 1571-1606
  5. 1997Cruciani, Giuseppe, Artioli, Gilberto, Gualtieri, Alessandro, Stahl, Kenny, Hanson, Jonathan C. (1997) Dehydration dynamics of stilbite using synchrotron X-ray powder diffraction. American Mineralogist, 82 (7) 729-739 doi:10.2138/am-1997-7-810 DOI: 10.2138/am-1997-7-810
