Straczekite

(Ca,K,Ba)(V5+,V4+)8O20 · 3H2O
IMA status
  • Approved
IMA symbol
Szk
Discovered
1983
IMA approved
1983
Also known as
  • IMA1983-028
  • Straczekiet

Where it forms, where it's found

Geological setting

A rare secondary mineral in fibrous seams in gangue.

Type locality
North Wilson pit
  1. Union Carbide Mine
  2. Wilson Springs (Potash Sulfur Springs)
  3. Garland County
  4. Arkansas
  5. USA

34.4778°, -92.9681°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Green-black
Streak
Greenish black
Cleavage
Perfect

(100)

Density
3.09 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
2
Surface relief
Very high
Principal indices
nα 2
Pleochroism
Weak

apple-green to olive-green

Dispersion
relatively weak

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 11.679(3) Å · b = 3.6608(4) Å · c = 10.636(2) Å
Cell angles
β = 100.53(4) °
Ratio a:b:c
1 : 0.313 : 0.911
Z
1
Twinning

On (001), possible, observed by X-ray diffraction.

Type-locality form

Dark greenish-black crystals as thin laths up to 0.5 mm in length, forming thick masses.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
23VVanadiumVanadium1650.942815.072
57.99%
8OOxygenOxygen2315.999367.977
26.18%
56BaBariumBarium1137.327137.327
9.77%
20CaCalciumCalcium140.07840.078
2.85%
19KPotassiumPotassium139.09839.098
2.78%
1HHydrogenHydrogen61.0086.048
0.43%
Total1405.600100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1983-028
  • Straczekiet

In other languages

German
IMA 1983-028 · Straczekit
Italian
Straczekite

Classification

Strunz
10th ed.

4.HE.20

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HEPhyllovanadatesGroup
  • 4.HE.20StraczekiteSpecies
Dana
8th ed.

47.03.02.01

  • 47Vanadium OxysaltsClass
  • 47.03Hydrated Normal Vanadium OxysaltsType
  • 47.03.02Straczekite GroupGroup
  • 47.03.02.01StraczekiteSpecies
CIM

21.2.15

  • 21Vanadates (and vanadates with arsenate or phosphate)Class
  • 21.2Vanadates of Mg, Ca, Sr or BaGroup
  • 21.2.15StraczekiteSpecies

Group, growth & confusion

In the same group
4 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1983Kutoglu, A. (1983) Kristallstruktur der calcium-vanadium-bronze CaxV4+2xV5+2-2xO5. Zeitschrift für Kristallographie: 162: 263-272.
  2. 1984Evans, Howard T., Nord, Gordon, Marinenko, John, Milton, Charles (1984) Straczekite, a new calcium barium potassium vanadate mineral from Wilson Springs, Arkansas. Mineralogical Magazine, 48 (347) 289-293 doi:10.1180/minmag.1984.048.347.16 DOI: 10.1180/minmag.1984.048.347.16
  3. 1985Dunn, Pete J., Fleischer, Michael, Langley, Richard H., Shigley, James E., Zilczer, Janet A. (1985) New mineral names. American Mineralogist, 70 (7-8) 871-881
  4. 1990Evans, Howard T., Jr.,, Hughes, John M. (1990) Crystal chemistry of the natural vanadium bronzes. American Mineralogist, 75 (5-6) 508-521
  5. 2005(2005) Straczekite. Handbook of Mineralogy. Mineralogical Society of America
