Trolleite

Al4(PO4)3(OH)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Tll
Discovered
1868
Also known as
  • Trolleiet

Where it forms, where it's found

Geological setting

Peraluminous high pressure rocks.

Type locality
Västanå Iron Mine (Westanå Mine)
  1. Näsum
  2. Bromölla
  3. Skåne County
  4. Sweden

56.1951°, 14.4622°

18recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Light green · colorless · bluish green · (dark blue when included)

Scorzalite-lazulite may be admixed.

Streak
White
Tenacity
brittle
Cleavage
Poor/Indistinct

Two directions at an angle of 110°52'.

Fracture
Irregular/Uneven · Sub-Conchoidal
Density
3.10 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 49° · 2V calc = 46°
Refractive index
1.619 – 1.643
Surface relief
Moderate
Principal indices
nα 1.619 · nβ 1.639 · nγ 1.643
Birefringence
0.024
Dispersion
r < v strong
UV response
Not Fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0240
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]240 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation240 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 18.894 Å · b = 7.161 Å · c = 7.162 Å
Cell angles
β = 99.99 °
Ratio a:b:c
1 : 0.379 : 0.379
Z
4
Morphology

Massive, lamellar.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
54.07%
13AlAluminiumAluminium426.982107.928
24.32%
15PPhosphorusPhosphorus330.97492.922
20.93%
1HHydrogenHydrogen31.0083.024
0.68%
Total443.859100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Trolleiet

In other languages

German
Trolleit
Spanish
Trolleíta
Italian
Trolleite
Japanese
トロール石

Classification

Strunz
10th ed.

8.BB.45

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BBWith only medium-sized cations, (OH, etc.):RO4 about 1:1Group
  • 8.BB.45TrolleiteSpecies
Dana
8th ed.

41.11.01.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.11MiscellaneousType
  • 41.11.01— unnamed intermediate level —Group
  • 41.11.01.01TrolleiteSpecies
CIM

19.7.3

  • 19PhosphatesClass
  • 19.7Phosphates of Al aloneGroup
  • 19.7.3TrolleiteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1868Blomstrand, C. W. (1868) Om Vestanå Mineralier. Öfversigt af Kongl. vetenskaps-akademiens förhandlingar, 25. 197-212
  2. 1893Des Cloizeaux, A. (1893) Manuel de minéralogie. 2 volumes and Atlas, Paris. volume 2, 2 Fasc., pp 209-544: 453.
  3. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  4. 1964Sclar, C.B., Carrison, L.C., Schwartz, C.M. (1964) Synthesis and properties of trolleite (aluminian lazulite ?), a high pressure mineral from the Westana iron deposit, Kristianstad, Sweden. Geological Society of America, Special Paper 76, 145. (abs.)
  5. 1965Fleischer, Michael (1965) New Mineral Names. American Mineralogist, 50 (1-2) 261-268
