Rosemaryite

◻NaMn2+(Fe3+Al)(PO4)3
IMA status
  • Approved
IMA symbol
Rmy
Discovered
1979
Also known as
  • Rosemaryiet

Where it forms, where it's found

Geological setting

Granite pegmatite.

Granite pegmatite (Buranga).

Type locality
Rock Ridge pegmatite
  1. Custer
  2. Custer Mining District
  3. Custer County
  4. South Dakota
  5. USA
5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 4.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark olive-green · dark brown
Tenacity
brittle
Cleavage
Distinct/Good

(010) {1</mi01>}, by analogy with ferrowyllieite

Fracture
Irregular/Uneven
Density
3.63 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 80° · 2V calc = 76°
Refractive index
1.723 – 1.758
Surface relief
High
Principal indices
nα 1.723 · nβ 1.742 · nγ 1.758
Birefringence
0.035
Pleochroism
Visible

X = Y = pale brownish yellow, Z = pale greenish yellow

Dispersion
r > v weak
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0350
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]350 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation350 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 11.977 Å · b = 12.388 Å · c = 6.320 Å
Cell angles
β = 114.45 °
Ratio a:b:c
1 : 1.034 : 0.528
Z
4
Type-locality form

Dark greenish black monocrystalline masses.

Comment

P21/n

Crystal structure

Synonyms

  • Rosemaryiet

In other languages

German
Rosemaryit
Italian
Rosemaryite

Classification

Strunz
10th ed.

8.AC.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.15RosemaryiteSpecies
Dana
8th ed.

38.02.04.03

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.02(AB)5(XO4)3Type
  • 38.02.04Alluaudite-Wyllieite Group (Wyllieite Subgroup)Group
  • 38.02.04.03RosemaryiteSpecies
CIM

19.14.3

  • 19PhosphatesClass
  • 19.14Phosphates of Fe and other metalsGroup
  • 19.14.3RosemaryiteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1979Moore, Paul B., Ito, Jun (1979) Alluaudites, wyllieites, arrojadites: crystal chemistry and nomenclature. Mineralogical Magazine, 43 (326) 227-235 doi:10.1180/minmag.1979.043.326.04 DOI: 10.1180/minmag.1979.043.326.04
  2. 1980Fleischer, Michael, Cabri, Louis J., Chao, G. Y., Pabst, Adolf (1980) New Mineral Names. American Mineralogist, 65 (7-8) 808-814
  3. 1995Fransolet, André-Mathieu (1995) Wyllieite et rosemaryite dans la pegmatite de Buranga, Rwanda. European Journal of Mineralogy, 7 (3) 567-576 doi:10.1127/ejm/7/3/0567DOI: 10.1127/ejm/7/3/0567
  4. 2005(2005) Rosemaryite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2006Hatert, Frédéric, Hermann, Raphaël P., Fransolet, André-Mathieu, Long, Gary J., Grandjean, Fernande (2006) A structural, infrared, and Mossbauer spectral study of rosemaryite, NaMnFe3+Al(PO4)3. European Journal of Mineralogy, 18 (6) 775-785 doi:10.1127/0935-1221/2006/0018-0775DOI: 10.1127/0935-1221/2006/0018-0775
