Tsepinite-Ca

(Ca,K,Na)2-x(Ti,Nb)2(Si4O12)(OH,O)2 · 4H2O
IMA status
  • Approved
IMA symbol
Tsp-Ca
IMA approved
2002
Also known as
  • IMA2002-020
  • Tsepiniet-Ca

Where it forms, where it's found

Geological setting

In cavities of replaced rinkite.

Type locality
Lovchorrite Mine
  1. Hackman Valley
  2. Yukspor Mountain
  3. Murmansk Oblast
  4. Russia
5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
White · colourless · pale brownish
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.73 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 30° · 2V calc = 36°
Refractive index
1.666 – 1.78
Surface relief
High
Principal indices
nα 1.666 · nβ 1.676 · nγ 1.78
Pleochroism
Non-pleochroic
Dispersion
very weak: r < n.
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.1140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1140 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1140 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.484 Å · b = 14.191 Å · c = 7.907 Å
Cell angles
β = 117.26 °
Ratio a:b:c
1 : 0.980 : 0.546
Z
4
Morphology

Combine both in sheaf-like clusters up to 2 x 6 mm large and chaotic open-worked aggregates up to 1 cm as maximum dimension.

Type-locality form

Coarse long-prismatic to needle-shaped crystals up to 0.2 x 0.6 x 5mm in size.

Crystal structure

Chemical composition

Impurities
  • K
  • Na

Synonyms

  • IMA2002-020
  • Tsepiniet-Ca

In other languages

German
IMA 2002-020 · Tsepinit-Ca
Italian
tsepinite-Ca

Classification

Strunz
10th ed.

9.CE.30b

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.30bTsepinite-CaSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 2003Pekov, Igor V., Chukanov, Nikita V., Ferraris, Giovanni, Gula, Angela, Pushcharovsky, Dmitry Yu., Zadov, Aleksandr E. (2003) Tsepinite–Ca, (Ca,K,Na,□)2(Ti,Nb)2(Si4O12) (OH,O)2·4H2O, a new mineral of the labuntsovite group from the Khibiny alkaline massif, Kola Peninsula – Novel disordered sites in the vuoriyarvite-type structure. Neues Jahrbuch für Mineralogie - Monatshefte, 2003 (10) 461-480 doi:10.1127/0028-3649/2003/2003-0461DOI: 10.1127/0028-3649/2003/2003-0461
  2. 2021(2021) Tsepinite-Ca. Handbook of Mineralogy. Mineralogical Society of America
