Bassetite

Fe2+(UO2)2(PO4)2(H2O)10
IMA status
  • Approved
  • Grandfathered
IMA symbol
Bas
Discovered
1915
Also known as
  • Bassetiet

Where it forms, where it's found

Geological setting

Oxdized zones of uranium-bearing hydrothermal deposits.

Type locality
Wheal Basset
  1. Basset Mines
  2. Carnkie
  3. Carn Brea
  4. Cornwall
  5. England
  6. UK

50.2138°, -5.2372°

52recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
brownish yellow · olive-green · yellow · bronze-yellow.

Observed as sectored in transmitted light due to twinning

Streak
Pale yellow to greenish white
Tenacity
brittle
Cleavage
Perfect

On (010), perfect; on (100) and (001), good/distinct.

Fracture
Micaceous
Density
3.40 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 90° · 2V calc = 88°
Refractive index
1.603 – 1.617
Surface relief
Moderate
Principal indices
nα 1.603 · nβ 1.610 · nγ 1.617
Birefringence
0.014
Pleochroism
Visible

X = b = Pale yellow Y = Deep yellow Z = ^c -4° = Deep yellow (sometimes dark olive brown to brownish black)

Dispersion
strong r > v
Extinction
Y^c = 18.5°, X=b
UV response
Not fluorescent in UV.
Notes

Biaxial negative property probable.

Michel-Lévy diagramhighlighted lineδ = 0.0140
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]140 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation140 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.961(1) Å · b = 20.039(2) Å · c = 6.974(1) Å
Cell angles
β = 90.46(1) °
Ratio a:b:c
1 : 2.879 : 1.002
Z
2
Morphology

Crystals thin tablets, flattened on [010], with a square or rectangular outline, and exhibiting (111), (101), (110), (001), and (010). Commonly in parallel or fanlike groups.

Twinning

Common, with two or more individuals at ~90° with [001] of one individual parallel to [100] of the other, with the contact surface being (010) in some instances, and (110) against (011) in other instances.

Type-locality form

Fan-like groups of almost parallel tabular crystals.

Comment

Space group P21/n (previous one: P21/m). Pseudotetragonal; synthetic material. Originall given cell: a = 6.98, b = 17.07, c = 7.01 Å, β = 90.53°.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
49.28%
8OOxygenOxygen2215.999351.978
36.44%
15PPhosphorusPhosphorus230.97461.948
6.41%
26FeIronIron155.84555.845
5.78%
1HHydrogenHydrogen201.00820.160
2.09%
Total965.989100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bassetiet

In other languages

German
Bassetit
Italian
Bassetite

Classification

Strunz
10th ed.

8.EB.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.EUranyl phosphates and arsenatesDivision
  • 8.EBUO2:RO4 = 1:1Group
  • 8.EB.10BassetiteSpecies
Dana
8th ed.

40.2a.16.01

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.2aAB2(XO4)2·xH2O, containing (UO2)2+Type
  • 40.2a.16— unnamed intermediate level —Group
  • 40.2a.16.01BassetiteSpecies
CIM

19.11.41

  • 19PhosphatesClass
  • 19.11Phosphates of UGroup
  • 19.11.41BassetiteSpecies

Group, growth & confusion

Often grow together
5 minerals
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1915Hallimond, A. F. (1915) On Bassetite and Uranospathite, new species hitherto classed as Autunite. Mineralogical Magazine and Journal of the Mineralogical Society, 17 (81) 221-236 doi:10.1180/minmag.1915.017.81.11 DOI: 10.1180/minmag.1915.017.81.11
  2. 1939Meixner (1939) Naturwissenschaftliche Abhandlungen, Vienna: 27: 454.
  3. 1940Meixner, H. (1940) Fluoreszenzanalytische, optische und chemische Beobachtungen an Uranmineralen (Fluorescence, optical and chemical observations of uranium minerals). Chemie der Erde: 12: 433-450.
  4. 1941(1941) New mineral names. American Mineralogist, 26 (3) 235-236
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
