Ussingite

Na2AlSi3O8(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Usg
Discovered
1914
Also known as
  • Ussingiet

Where it forms, where it's found

Geological setting

Syenite pegmatite, also sodalite-bearing xenoliths

Type locality
Kangerluarsuk Fjord
  1. Ilímaussaq complex
  2. Kujalleq
  3. Greenland

60.8759°, -45.8737°

26recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pale to medium violet · reddish violet · colourless · white · purple
Streak
white
Tenacity
brittle
Cleavage

(001) perfect (110} perfect

Fracture
Irregular/Uneven
Density
2.48 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 32 – 39° · 2V calc = 42°
Refractive index
1.504 – 1.545
Surface relief
Moderate
Principal indices
nα 1.504 · nβ 1.509 · nγ 1.545
Birefringence
0.041
Dispersion
none
Extinction
Z angle b = 3˚
UV response
Not fluorescent
Michel-Lévy diagramhighlighted lineδ = 0.0410
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]410 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation410 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 7.256 Å · b = 7.686 Å · c = 8.683 Å
Cell angles
α = 90.75 ° · β = 99.75 ° · γ = 122.48 °
Ratio a:b:c
1 : 1.059 : 1.197
Z
2
Morphology

Crystals uncommon; blocky to tabular with dominant pinacoidal forms (100), (010), and (001)

Twinning

(010)

Comment

Williams & Weller (2012) data: a=7.2474(1), b=7.6813(1), c=8.6423(1), α=90.8351(1), β=99.771(1), γ=122.581(1)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
47.65%
14SiSiliconSilicon328.08584.255
27.88%
11NaSodiumSodium222.99045.980
15.21%
13AlAluminiumAluminium126.98226.982
8.93%
1HHydrogenHydrogen11.0081.008
0.33%
Total302.216100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca
  • K
  • Cl
  • H2O
  • S

Synonyms

  • Ussingiet

In other languages

French
Ussingite
German
Ussingit
Spanish
Ussingita
Italian
Ussingite
Chinese
紫脆石
Arabic
أسينايت · أوسينغيت

Classification

Strunz
10th ed.

9.EH.20

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EHTransitional structures between phyllosilicate and other silicate unitsGroup
  • 9.EH.20UssingiteSpecies
Dana
8th ed.

76.03.03.01

  • 76Tectosilicates Al-si FrameworkClass
  • 76.03Al-Si Framework with other Be/Al/Si frameworksType
  • 76.03.03— unnamed intermediate level —Group
  • 76.03.03.01UssingiteSpecies
CIM

16.2.3

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.2Aluminosilicates of NaGroup
  • 16.2.3UssingiteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. 1915Bøggild, O.B. (1915) Ussingit, et nyt mineral fra Kangerdluarsuk [Ussingite, a new mineral from Kangerdluarsuk]. Meddelelser om Grønland, 51. 103-110
  2. 1915Böggild, Ο. B. (1915) Ussingit, ein neues Mineral von Kangerdluarsuk. Zeitschrift für Kristallographie, 54 (1-6). 120-126 doi:10.1524/zkri.1915.54.1.120DOI: 10.1524/zkri.1915.54.1.120
  3. 1974Rossi, Guiseppe, Tazzoli, Vittorio, Ungaretti, and Luciano (1974) The crystal structure of ussingite. American Mineralogist, 59 (3-4) 335-340
  4. 1990Horváth, László, Gault, Robert A. (1990) The Mineralogy of Mont Saint-Hilaire, Quebec. The Mineralogical Record, 21 (4) 281-359
  5. 2001(2001) Ussingite. Handbook of Mineralogy. Mineralogical Society of America
