Veenite

Pb2(Sb,As)2S5
IMA status
  • Approved
IMA symbol
Vee
Discovered
1966
IMA approved
1966
Also known as
  • IMA1966-016
  • Stibiodufrenoysit
  • Stibiodufrenoysita
  • +2 more

Where it forms, where it's found

Geological setting

Marbles produced from Precambrian metasedimentary rocks, formed at the margin of a plutonic intrusion.

Type locality
Taylor Pit
  1. Madoc
  2. Centre Hastings Municipality
  3. Hastings County
  4. Ontario
  5. Canada

44.5022°, -77.4664°

14recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Steel-gray
Streak
Black with weak brown tint
Fracture
Conchoidal

Optical

Pleochroism
Weak

White to pale pinkish gray

Optical colour
White
Anisotropism
Moderate
Tropism
Anisotropic
Reflectance R%
(40.2,43.8) 400, (39.9,43.4) 420, (39.6,43.0) 440, (39.2,42.8) 460, (38.8,42.6) 480, (38.4,42.3) 500, (37.9,42.0) 520, (37.4,41.7) 540, (37.0,41.4) 560, (36.5,40.8) 580, (36.1,40.3) 600, (35.7,39.8) 620, (35.3,39.1) 640, (34.7,38.4) 660, (34.0,37.6) 680, (33.3,36.8) 700
Reflected-light panel
37.1 %anisotropic · dual curve
Specimen sRGB 213, 152, 87
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Moderate
Reflected colour
White

Crystallography

Crystal system
Monoclinic
Space group
P21
Cell parameters
a = 8.429(2) Å · b = 26.069(5) Å · c = 8.962(2) Å
Cell angles
β = 117.447(2) °
Ratio a:b:c
1 : 3.093 : 1.063
Z
1
Type-locality form

Masses up to 2 cm in diameter. Disseminated anhedral grains.

Comment

Data from Topa & Makovicky (2017). Orthorhombic pseudocell with a' = 0.5a = 4.22, b = 26.2, c = 7.90 Å. Space group of the pseudocell is P21cn or Pmcn. The X-ay powder pattern closely resembles that of dufrénoysite.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
42.81%
51SbAntimonyAntimony2121.760243.520
25.15%
16SSulfurSulfur532.060160.300
16.56%
33AsArsenicArsenic274.922149.844
15.48%
Total968.064100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1966-016
  • Stibiodufrenoysit
  • Stibiodufrenoysita
  • Stibiodufrenoysite
  • Veeniet

In other languages

German
IMA 1966-016 · Veenit
Italian
Veenite

Classification

Strunz
10th ed.

2.HC.05d

  • 2Sulfides and SulfosaltsClass
  • 2.HSulfosalts of SnS archetypeDivision
  • 2.HCWith only PbGroup
  • 2.HC.05dVeeniteSpecies
Dana
8th ed.

03.05.09.02

  • 03SulfosaltsClass
  • 03.052.5 < ø < 3Type
  • 03.05.09Cosalite GroupGroup
  • 03.05.09.02VeeniteSpecies
CIM

5.6.20

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.6Sulpharsenites etc. of Pb aloneGroup
  • 5.6.20VeeniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1967Jambor, John Leslie (1967) New lead sulfantimonides from Madoc, Ontario. Part 1. The Canadian Mineralogist, 9 (1) 7-24
  2. 1967Jambor, John Leslie (1967) New lead sulfantimonides from Madoc, Ontario. Part 2 - mineral descriptions. The Canadian Mineralogist, 9 (2) 191-213
  3. 1968Jambor, John Leslie (1968) New lead sulfantimonides from Madoc, Ontario. Part 3--Syntheses, paragenesis, origin. The Canadian Mineralogist, 9 (4). 505-521
  4. 1973Walia, D. S., Chang, L. L. Y. (1973) Investigations in the systems PbS-Sb2S3-As2S3 and PbS-Bi2S3-As2S3. The Canadian Mineralogist, 12 (2) 113-119
  5. 1982Jambor, John L.; Laflamme, J. H. G.; Walker, D. A. (1982) A Re-examination of the Madoc Sulfosalts, in Ontario. The Mineralogical Record, 13 (2). 93-100
