Yofortierite

Mn2+5Si8O20(OH)2 · 7H2O
IMA status
  • Approved
IMA symbol
Yof
Discovered
1974
IMA approved
1974
Also known as
  • IMA1974-045
  • Mn-Palygorskite
  • Mn-Sepiolite
  • +2 more

Where it forms, where it's found

Geological setting

A late-stage hydrothermal mineral in pegmatite veins in nepheline syenite.

Type locality
Poudrette quarry (De-Mix quarry
  1. Demix quarry
  2. Uni-Mix quarry
  3. Carrière Mont Saint-Hilaire
  4. MSH)
  5. Mont Saint-Hilaire
  6. La Vallée-du-Richelieu RCM
  7. Montérégie
  8. Québec
  9. Canada

45.5628°, -73.1417°

9recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Pink to pale violet · brown
Density
2.18 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.53 – 1.559
Surface relief
Moderate
Principal indices
nα 1.53 · nγ 1.559
Pleochroism
Visible
Dispersion
weak
Extinction
X ∧ fiber axis = 8°.
Notes

Absorption: Maximum ⊥ length of fibers.

Michel-Lévy diagramhighlighted lineδ = 0.0290
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]290 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation290 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.1686 Å · b = 17.8583 Å · c = 5.2919 Å
Cell angles
β = 105.878 °
Ratio a:b:c
1 : 1.260 : 0.373
Unit cell volume
1287.9 ų
Z
4
Morphology

Radiating fibres, single crystals are thin, about 1 micron.

Type-locality form

Radiating fibres.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2915.999463.971
47.37%
25MnManganeseManganese554.938274.690
28.04%
14SiSiliconSilicon828.085224.680
22.94%
1HHydrogenHydrogen161.00816.128
1.65%
Total979.469100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Cr
  • Zn
  • Ca
  • K

Synonyms

  • IMA1974-045
  • Mn-Palygorskite
  • Mn-Sepiolite
  • Unnamed (MSH UK-31)
  • Yofortieriet

In other languages

German
IMA 1974-045 · Yofortierit
Spanish
Yofortierita
Italian
Yofortierite
Russian
Йофортьерит

Classification

Strunz
10th ed.

9.EE.20

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EESingle tetrahedral nets of 6-membered rings connected by octahedral nets or octahedral bandsGroup
  • 9.EE.20YofortieriteSpecies
Dana
8th ed.

74.03.1a.03

  • 74Phyllosilicates Modulated LayersClass
  • 74.03Modulated Layers with joined stripsType
  • 74.03.1a— unnamed intermediate level —Group
  • 74.03.1a.03YofortieriteSpecies
CIM

14.17.10

  • 14Silicates not Containing AluminumClass
  • 14.17Silicates of MnGroup
  • 14.17.10YofortieriteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1975Perrault, G., Harvey, Y., Pertsowsky, R. (1975) La yofortierite, un nouveau silicate hydraté de manganése de St Hilaire, P. Q. The Canadian Mineralogist, 13 (1) 68-74
  2. 1976Fleischer, Michael, Chao, George Y., Mandarino, Joseph A. (1976) New Mineral Names. American Mineralogist, 61 (3-4) 338-341
  3. 1998Horváth, László, Gault, Robert A., Tarassoff, Peter, Pfenninger-Horváth, Elsa (1998) Mineralogy of the Saint-Amable Sill, Varennes and Saint-Amable, Quebec. The Mineralogical Record, 29 (2) 83-118
  4. 2001(2001) Yofortierite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2013Hawthorne, F. C., Abdu, Y. A., Tait, K. T., Back, M. E. (2013) The crystal structure of yofortierite. The Canadian Mineralogist, 51 (2) 243-251 doi:10.3749/canmin.51.2.243DOI: 10.3749/canmin.51.2.243
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Yofortierite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/yofortierite-4364},
  note      = {Accessed 2026-05-11}
}
