Aluminosugilite

KNa2Al2Li3Si12O30
IMA status
  • Approved
IMA symbol
Asug
IMA approved
2019
Also known as
  • Aluminosugiliet
  • Aluminosugilit
  • Aluminosugilitt
  • +2 more

Where it forms, where it's found

Geological setting

Manganiferous metacherts

Type locality
Cerchiara Mine
  1. Borghetto di Vara
  2. La Spezia Province
  3. Liguria
  4. Italy

44.1983°, 9.7075°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 6.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Pinkish-purple
Streak
Pale purple to white
Cleavage
Poor/Indistinct

On (0001)

Density
2.71 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.575 – 1.586
Surface relief
Moderate
Principal indices
nω 1.577 – 1.586 · nε 1.575 – 1.585
Pleochroism
Weak
Michel-Lévy diagramhighlighted lineδ = 0.0015
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]15 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation15 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P6/mcc
Cell parameters
a = 9.9830(4) Å · c = 13.9667(5) Å
Unit cell volume
1205.45 ų
Type-locality form

Aggregates of small prismatic and/or granular crystals up to 1 mm in length

Comment

Cell parameters for single crystal X-ray. Powder gave slightly smaller dimensions.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
49.14%
14SiSiliconSilicon1228.085337.020
34.50%
13AlAluminiumAluminium226.98253.964
5.52%
11NaSodiumSodium222.99045.980
4.71%
19KPotassiumPotassium139.09839.098
4.00%
3LiLithiumLithium36.94020.820
2.13%
Total976.852100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Aluminosugiliet
  • Aluminosugilit
  • Aluminosugilitt
  • IMA2018-142
  • Unnamed (Al-dominant analog of Sugilite)

In other languages

German
Aluminosugilith · IMA 2018-142

Classification

Strunz
10th ed.

9.CM.9.CM.

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CM[Si6O18]12- 6-membered double rings (sechser-Doppelringe)Group
  • 9.CM.9.CM.AluminosugiliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1988Lucchetti, G., Cortesogno, L., Palenzona, A. (1988) Low-temperature metamorphic mineral assemblages in Mn-Fe ores from Cerchiara mine (northern Appennine, Italy). Neues Jahrbuch für Mineralogie, Monatshefte: 8: 367-383.
  2. 1989HIROWATARI, Fumitoshi, FUKUOKA, Masato (1989) Some Problems of the studies on the manganese minerals in Japan. Journal of the Mineralogical Society of Japan, 18 (6) 347-365 doi:10.2465/gkk1952.18.347 DOI: 10.2465/gkk1952.18.347
  3. 1990Cabella, R., Lucchetti, G., Palenzona, A. (1990) Al-rich, Fe-poor manganoan sugilite in a pectolite-bearing assemblage from Cerchiara Mine (Northern Apennines, Italy). Neues Jahrbuch für Mineralogie, Monatshefte: 10: 443-448.
  4. 2019Miyawaki, Ritsuro, Hatert, Frédéric, Mills, Stuart J. (2019) New minerals and nomenclature modifications approved in 2019. CNMNC Newsletter 49. Mineralogical Magazine, 83 (3) 479-483 doi:10.1180/mgm.2019.35 DOI: 10.1180/mgm.2019.35
  5. 2020Nagashima, Mariko, Fukuda, Chihiro, Matsumoto, Takashi, Imaoka, Teruyoshi, Odicino, Gianluca, Armellino, Gianluca (2020) Aluminosugilite, KNa2Al2Li3Si12O30, an Al analogue of sugilite, from the Cerchiara mine, Liguria, Italy. European Journal of Mineralogy, 32 (1) 57-66 doi:10.5194/ejm-32-57-2020 DOI: 10.5194/ejm-32-57-2020
