Chayesite

KMg4Fe3+[Si12O30]
IMA status
  • Approved
IMA symbol
Cys
Discovered
1987
IMA approved
1987
Also known as
  • Chayesiet
  • IMA1987-059

Where it forms, where it's found

Geological setting

Rock forming mineral in lamproite

Type locality
Moon Canyon
  1. Woodland
  2. Summit County
  3. Utah
  4. USA

40.6219°, -111.2311°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Blue · brown · red

May have oxidised coatings.

Tenacity
brittle
Cleavage
None Observed
Density
2.68 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.575 – 1.578
Surface relief
Moderate
Principal indices
nω 1.575 · nε 1.578
Pleochroism
Strong

O= sky blue E= colorless

Michel-Lévy diagramhighlighted lineδ = 0.0030
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]30 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation30 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
P6/mcc
Cell parameters
a = 10.153(4) Å · c = 14.388(6) Å
Z
2
Type-locality form

Laths to 100 microns.

Comment

Space group by analogy to osumilite

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3015.999479.970
47.56%
14SiSiliconSilicon1228.085337.020
33.40%
12MgMagnesiumMagnesium424.30597.220
9.63%
26FeIronIron155.84555.845
5.53%
19KPotassiumPotassium139.09839.098
3.88%
Total1009.153100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Al
  • Mn
  • Na
  • K

Synonyms

  • Chayesiet
  • IMA1987-059

In other languages

German
Chayesit · IMA 1987-059
Italian
chayesite
Portuguese
Chayesita · IMA1987-059

Classification

Strunz
10th ed.

9.CM.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CM[Si6O18]12- 6-membered double rings (sechser-Doppelringe)Group
  • 9.CM.05ChayesiteSpecies
Dana
8th ed.

63.02.1a.02

  • 63Cyclosilicates Condensed RingsClass
  • 63.02Condensed Rings (Milarite - Osumilite group)Type
  • 63.02.1a— unnamed intermediate level —Group
  • 63.02.1a.02ChayesiteSpecies
CIM

14.24.6

  • 14Silicates not Containing AluminumClass
  • 14.24Silicates of Fe, Mg and alkalisGroup
  • 14.24.6ChayesiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. https://www.mindat.org/mesg-655941.html
  2. 1989Velde, D., Medenbach, O., Wagner, C., Schreyer, W. (1989) Chayesite, K(Mg,Fe2+)4Fe3+[Si12O30]: A new rock-forming silicate mineral of the osumilite group from the Moon Canyon (Utah) lamproite. American Mineralogist: 74: 1368-1373. [https://rruff.info/uploads/AM74_1368.pdf]
  3. 1994Alietii, E., Brigatti, M. F., Capedri, S., Poppi, L. (1994) The roedderite-chayesite series from Spanish lamproites: crystal-chemical characterization. Mineralogical Magazine, 58 (393) 655-662 doi:10.1180/minmag.1994.058.393.16 DOI: 10.1180/minmag.1994.058.393.16
  4. 2001(2001) Chayesite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2020Zubkova, Natalia V., Chukanov, Nikita V., Schäfer, Christof, Van, Konstantin V., Pekov, Igor V., Pushcharovsky, Dmitry Yu. (2020) Al analogue of chayesite from a lamproite of Cancarix, SE Spain, and its crystal structure. Neues Jahrbuch für Mineralogie - Abhandlungen, 196 (3). 193-198 doi:10.1127/njma/2020/0193DOI: 10.1127/njma/2020/0193
