Armenite

BaCa2(Al6Si9)O30 · 2H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Amn
Discovered
1939
Also known as
  • Armeniet

Where it forms, where it's found

Geological setting

A silver-bearing calcite-vein, Kongsberg, Norway.

Type locality
Armen Mine
  1. Overberget Mining Field
  2. Kongsberg
  3. Buskerud
  4. Norway

59.6505°, 9.5937°

19recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Colourless · white · green
Streak
White
Cleavage
Perfect

Perfect prismatic. One distinct pinacoidal.

Density
2.77 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 59 – 60° · 2V calc = 72°
Refractive index
1.55 – 1.556
Surface relief
Moderate
Principal indices
nα 1.55 · nβ 1.552 · nγ 1.556
Dispersion
r < v strong
Extinction
X = c; Z = b.
Michel-Lévy diagramhighlighted lineδ = 0.0060
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]60 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation60 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pnna
Cell parameters
a = 13.874(2) Å · b = 18.660(2) Å · c = 10.697(1) Å
Ratio a:b:c
1 : 1.345 : 0.771
Morphology

Prismatic pseudohexagonal crystals.

Twinning

The pseudohexagonal form is due to twinning along an axis parallel to the optic direction a.

Parting
Along sector boundaries.
Comment

Space group is Pnna. Symmetry reduction is due to partial ordering of Si and Al. Ordering of water gives primitive orthorhombic unit cell.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3215.999511.968
44.59%
14SiSiliconSilicon928.085252.765
22.02%
13AlAluminiumAluminium626.982161.892
14.10%
56BaBariumBarium1137.327137.327
11.96%
20CaCalciumCalcium240.07880.156
6.98%
1HHydrogenHydrogen41.0084.032
0.35%
Total1148.140100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Sr
  • Na
  • K

Synonyms

  • Armeniet

In other languages

German
Armenit
Italian
Armenite

Classification

Strunz
10th ed.

9.CM.05

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CM[Si6O18]12- 6-membered double rings (sechser-Doppelringe)Group
  • 9.CM.05ArmeniteSpecies
Dana
8th ed.

63.02.1b.01

  • 63Cyclosilicates Condensed RingsClass
  • 63.02Condensed Rings (Milarite - Osumilite group)Type
  • 63.02.1b— unnamed intermediate level —Group
  • 63.02.1b.01ArmeniteSpecies
CIM

16.12.12

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.12Aluminosilicates of Sr, Ba and ZnGroup
  • 16.12.12ArmeniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1940Neumann, Heinrich (1940) Armenite, a new mineral. Preliminary note. Norsk Geologisk Tidsskrift [Norwegian Journal of Geology], 19 (4). 312-313
  2. 1941(1941) New mineral names. American Mineralogist, 26 (3) 235-236
  3. 1941Neumann, Henrich (1941) Armenite, a water-bearing barium-calcium-alumosilicate. Norsk Geologisk Tidsskrift [Norwegian Journal of Geology], 21 (1). 19-24
  4. 1984Pouliot, G., Trudel, P., Valiquette, G., Samson, P. (1984): Armenite - thulite - albite veins at Remigny, Quebec: the second occurrence of armenite. The Canadian Mineralogist: 22: 453-464.
  5. 1987Mason, Brian (1987) Armenite from Broken Hill, Australia, with comments on calciocelsian and barium anorthite. Mineralogical Magazine, 51 (360) 317-318 doi:10.1180/minmag.1987.051.360.15 DOI: 10.1180/minmag.1987.051.360.15
