Arsenbrackebuschite

Pb2(Fe3+,Zn)(AsO4)2(OH,H2O)
IMA status
  • Approved
IMA symbol
Abbs
Discovered
1978
Also known as
  • Arsenbrackebuschiet
  • Arsenbrackebuschitt
  • Arsenbrackenbuschit
  • +3 more

Where it forms, where it's found

Geological setting

Oxide zone of a complex polymetallic ore hydrothermal deposit

Type locality
Clara Mine
  1. Oberwolfach
  2. Ortenaukreis
  3. Freiburg Region
  4. Baden-Württemberg
  5. Germany

48.3797°, 8.2289°

24recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine · Resinous
Transparency
Transparent · Translucent
Colour
Light amber yellow to red brown
Streak
Light brownish yellow
Tenacity
brittle
Cleavage
Perfect

(010)

Density
6.54 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 30°
Refractive index
2 – 2.04
Surface relief
Very high
Principal indices
nα 2 · nγ 2.04
Birefringence
0.04
Dispersion
relatively weak
UV response
Not fluorescent.
Notes

RI difficult to measure; X' < 2.00, Z" > 2.04.

Michel-Lévy diagramhighlighted lineδ = 0.0400
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]400 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation400 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P2/m
Cell parameters
a = 7.763 Å · b = 6.046 Å · c = 9.022 Å
Cell angles
β = 112.5 °
Ratio a:b:c
1 : 0.779 : 1.162
Z
2
Morphology

Wedge-shaped crystals, also elongated.

Type-locality form

Flat laths or platelets, with max dimensions 0.5 mm long, 0.2 mm wide, 0.1 mm thick, on fissures in dolomite breccia.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
48.84%
8OOxygenOxygen1015.999159.990
18.86%
33AsArsenicArsenic274.922149.844
17.66%
30ZnZincZinc165.38065.380
7.70%
26FeIronIron155.84555.845
6.58%
1HHydrogenHydrogen31.0083.024
0.36%
Total848.483100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Arsenbrackebuschiet
  • Arsenbrackebuschitt
  • Arsenbrackenbuschit
  • Arsenbrackenbuschita
  • Arsenbrackenbuschite
  • IMA1977-014

In other languages

German
Arsenbrackebuschit · IMA 1977-014
Italian
arsenbrackebuschite
Chinese
砷铁铅石

Classification

Strunz
10th ed.

8.BG.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BGWith medium-sized and large cations, (OH, etc.):RO4 = 0.5:1Group
  • 8.BG.05ArsenbrackebuschiteSpecies
Dana
8th ed.

40.02.08.02

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.02AB2(XO4)2·xH2OType
  • 40.02.08Brackebushite GroupGroup
  • 40.02.08.02ArsenbrackebuschiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1978Fleischer, Michael (1978) New mineral names. American Mineralogist, 63 (11-12). 1282-1284
  2. 1978Hofmeister, W., Tillmanns, E. (1978) Strukturelle Untersuchungen an Arsenbrackebuschit. TMPM Tschermaks Mineralogische und Petrographische Mitteilungen, 25 (3). 153-163 doi:10.1007/bf01081416DOI: 10.1007/bf01081416
  3. 1978Abraham, K., Kautz, K., Tillmanns, E., Walenta, K. (1978) Arsenbrackebuschite, Pb2(Fe,Zn)(OH,H2O)[AsO4]2, a new arsenate mineral. Neues Jahrbuch für Mineralogie - Monatshefte, 1978. 193-196
  4. 2005(2005) Arsenbrackebuschite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2017Cámara, F., Bittarello, E., Ciriotti, M. E., Nestola, F., Radica, F., Massimi, F., Balestra, C., Bracco, R. (2017) As-bearing new mineral species from Valletta mine, Maira Valley, Piedmont, Italy: III. Canosioite, Ba2Fe3+(AsO4)2(OH), description and crystal structure. Mineralogical Magazine, 81 (2) 305-317 doi:10.1180/minmag.2016.080.097 DOI: 10.1180/minmag.2016.080.097
