Arsentsumebite

Pb2Cu(AsO4)(SO4)(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Atsu
Discovered
1935
Also known as
  • Arsentsumebiet
  • Arsentsumebitt
  • As-Tsumebit
  • +1 more

Where it forms, where it's found

Geological setting

Oxidised zone of a dolostone-hosted hydrothermal polymetallic deposit.

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

35recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous to dull.
Transparency
Translucent
Colour
Emerald-green · grass-green · apple-green · pale bluish green.

Single crystals are generally pale.

Streak
(not reported)
Tenacity
brittle
Cleavage

(not reported)

Fracture
Irregular/Uneven
Density
6.46 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 88° · 2V calc = 84°
Refractive index
1.97 – 2.011
Surface relief
Very high
Principal indices
nα 1.97 · nβ 1.992 · nγ 2.011
Pleochroism
Visible

X = Pale pistachio-green Y = Z = Bottle-green

Dispersion
strong
Luminescence
None
Michel-Lévy diagramhighlighted lineδ = 0.0410
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]410 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation410 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#15
Cell parameters
a = 8.85 Å · b = 5.92 Å · c = 7.84 Å
Cell angles
β = 112.6 °
Ratio a:b:c
1 : 0.669 : 0.886
Morphology

Crystals distorted in aggregates and crusts.

Twinning

Observed, complex.

Type-locality form

distorted crystals, up to 2 mm, forming aggregates and crusts

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
56.77%
8OOxygenOxygen915.999143.991
19.73%
33AsArsenicArsenic174.92274.922
10.26%
29CuCopperCopper163.54663.546
8.71%
16SSulfurSulfur132.06032.060
4.39%
1HHydrogenHydrogen11.0081.008
0.14%
Total729.927100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Arsentsumebiet
  • Arsentsumebitt
  • As-Tsumebit
  • As-Tsumebite

In other languages

German
Arsentsumebit
Spanish
arsentsumebita
Italian
arsentsumebite

Classification

Strunz
10th ed.

8.BG.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BGWith medium-sized and large cations, (OH, etc.):RO4 = 0.5:1Group
  • 8.BG.05ArsentsumebiteSpecies
Dana
8th ed.

43.04.02.02

  • 43Compound Phosphates, Etc.Class
  • 43.04Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.04.02Tsumebite GroupGroup
  • 43.04.02.02ArsentsumebiteSpecies
CIM

22.3.16

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.3Phosphates, arsenates or vanadates with sulphatesGroup
  • 22.3.16ArsentsumebiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1935Vésignié, J.P.L. (1935) Présentation d'échantillons. Bulletin de la Société française de Minéralogie: 58: 4-5.
  2. 1966Bideaux, R.A., Nichols, M.C., Williams, S.A. (1966) The arsenate analogue of tsumebite, a new mineral. American Mineralogist: 51: 258-259.
  3. 1974Chudoba, K.F. (1974) Arsentsumebit. Handbuch der Mineralogie: 4: 5-5.
  4. 1994Schlüter, Jochen (1994) Tsumebit oder Arsentsumebit aus Tsumeb? [Tsumebite or Arsentsumebite from Tsumeb?]. Lapis, 19 (10). 31-34;86
  5. 2000Zubkova, N. V., Pushcharovsky, D. Yu., Giester, G., Tillmanns, E. (2000) The crystal structure of arsentsumebite, Pb2Cu[(As,S)O4)]2(OH) Acta Crystallographica Section A Foundations of Crystallography, 56. doi:10.1107/s0108767300027549DOI: 10.1107/s0108767300027549
