Calderite

Mn2+3Fe3+2(SiO4)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cdr
Discovered
1909
Also known as
  • Calderite (of Fermor)

Where it forms, where it's found

Geological setting

In a manganese deposit

Type locality
Scully mine
  1. Wabush Lake
  2. Labrador
  3. Newfoundland and Labrador
  4. Canada

52.9081°, -66.9231°

26recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark reddish brown to dark yellowish · brown-yellow
Density
4.05 g/cm³

Optical

Optical type
Isotropic
Surface relief
Very high
Principal indices
n 1.875 – 1.934
Notes

Shows slight anisotropism.

Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation
Single index
n = 1.905

Crystallography

Crystal system
Isometric
Space group
Ia3d
Cell parameters
a = 11.81 Å
Z
8
Type-locality form

Granular, massive.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1215.999191.988
34.73%
25MnManganeseManganese354.938164.814
29.82%
26FeIronIron255.845111.690
20.21%
14SiSiliconSilicon328.08584.255
15.24%
Total552.747100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mg

Synonyms

  • Calderite (of Fermor)

In other languages

French
Caldérite
German
Calderit
Spanish
Calderita
Italian
Calderite
Japanese
満鉄柘榴石
Chinese
锰铁榴石

Classification

Strunz
10th ed.

9.AD.25

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.ADNesosilicates without additional anions; cations in [6] and/or greater coordinationGroup
  • 9.AD.25CalderiteSpecies
Dana
8th ed.

51.04.3a.06

  • 51Nesosilicates Insular Sio4 Groups OnlyClass
  • 51.04Insular SiO4 Groups Only with cations in [6] and >[6] coordinationType
  • 51.04.3a— unnamed intermediate level —Group
  • 51.04.3a.06CalderiteSpecies
CIM

14.18.34

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.34CalderiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. American Mineralogist: 66: 1280.
  2. 1892Dana 6th (1892), 433.
  3. 1926Fermor, L. L. (1926): On the composition of some Indian garnets. Records Geol. Surv. India, 59, Pt. 2, 191-207.
  4. 1952Vermaas, F. H. S. (1952) Manganese-iron garnet from Otjosondu, South-West Africa. Mineralogical Magazine and Journal of the Mineralogical Society, 29 (218) 946-951 doi:10.1180/minmag.1952.029.218.07 DOI: 10.1180/minmag.1952.029.218.07
  5. 1966Klein, C. (1966) Mineralogy and petrology of the metamorphosed Wabush Iron Formation, southwestern Labrador. Journal of Petrology, 7 (2) 246-305 doi:10.1093/petrology/7.2.246DOI: 10.1093/petrology/7.2.246
