Carboirite

Fe2+Al2GeO5(OH)2
IMA status
  • Approved
IMA symbol
Cb
Discovered
1983
Also known as
  • Carboiriet
  • IMA1980-066

Where it forms, where it's found

Type locality
Carboire
  1. Ustou
  2. Saint-Girons
  3. Ariège
  4. Occitanie
  5. France

42.7520°, 1.2750°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Green
Cleavage
Distinct/Good

(001)

Density
3.95 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 65 – 70°
Refractive index
1.731 – 1.74
Surface relief
High
Principal indices
nα 1.731 · nβ 1.735 · nγ 1.74
Pleochroism
Visible

X = bluish green, Y = light blue, Z = colorless to yellow

Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 9.51 Å · b = 5.56 Å · c = 9.29 Å
Cell angles
α = 96.08 ° · β = 101.52 ° · γ = 89.45 °
Ratio a:b:c
1 : 0.585 : 0.977
Z
4
Morphology

Pseudo-hexagonal plates. Forms (001), (110), (010).

Twinning

Polysynthetic twinning // to (001).

Type-locality form

Green, pseudo-hexagonal plates (100 x 100 x 30 µm).

Comment

Space group c_1 as compared to monoclinic chloritoid

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
37.78%
32GeGermaniumGermanium172.63072.630
24.50%
26FeIronIron155.84555.845
18.84%
13AlAluminiumAluminium226.98253.964
18.20%
1HHydrogenHydrogen21.0082.016
0.68%
Total296.448100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Carboiriet
  • IMA1980-066

In other languages

German
Carboirit · IMA 1980-066
Italian
Carboirite · Carboirite-III · Carboirite-VIII

Classification

Strunz
10th ed.

9.J0.05

  • 9SilicatesClass
  • 9.JGermanatesDivision
  • 9.J0— unnamed intermediate level —Group
  • 9.J0.05CarboiriteSpecies
Dana
8th ed.

52.03.03.04

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.03Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] coordination onlyType
  • 52.03.03Chloritoid groupGroup
  • 52.03.03.04CarboiriteSpecies
CIM

7.11.17

  • 7Oxides and HydroxidesClass
  • 7.11Oxides of Sn and PbGroup
  • 7.11.17CarboiriteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1983Johan, Z.; Oudin, E.; Picot, P. (1983) Analogues germanifères et gallifères des silicates et oxydes dans les gisements de zinc des Pyrénées centrales, France; argutite et carboirite, deux nouvelles espèces minérales [Germanium and gallium analogs of silicates and oxides from zinc deposits of the French central Pyrenees; argutite and carboirite, two new mineral species]. TMPM Tschermaks Mineralogische und Petrographische Mitteilungen, 31 (1). 97-119 doi:10.1007/bf01084764DOI: 10.1007/bf01084764
  2. 1984Dunn, Pete J.; Cabri, Louis J.; Chao, George Y.; Fleischer, Michael; Francis, Carl A.; Grice, Joel D.; Jambor, John L.; Pabst, Adolf (1984) New mineral names. American Mineralogist, 69 (3-4). 406-412
