Ottrélite

Mn2+Al2O(SiO4)(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Otr
Discovered
1809
Also known as
  • Newportit
  • Newportita
  • Newportite
  • +1 more

Where it forms, where it's found

Type locality
Ottré
  1. Bihain
  2. Vielsalm
  3. Luxembourg
  4. Wallonia
  5. Belgium

50.2489°, 5.8366°

51recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Pistachio-green · greenish to dark grey
Streak
Greenish, greyish

Optical

Optical type
Biaxial (+) · 2V measured = 46 – 70° · 2V calc = 46 – 82°
Refractive index
1.709 – 1.732
Surface relief
High
Principal indices
nα 1.709 – 1.725 · nβ 1.712 – 1.726 · nγ 1.716 – 1.732
Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0070
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]70 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation70 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 9.505(6) Å · b = 5.484(4) Å · c = 18.214(15) Å
Cell angles
β = 101.77(3) °
Ratio a:b:c
1 : 0.577 : 1.916
Twinning

Polysynthetic, parallel to [001].

Comment

Space group Cc or C2/c. Pseudohexagonal.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen715.999111.993
44.62%
25MnManganeseManganese154.93854.938
21.89%
13AlAluminiumAluminium226.98253.964
21.50%
14SiSiliconSilicon128.08528.085
11.19%
1HHydrogenHydrogen21.0082.016
0.80%
Total250.996100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ca
  • H2O

Synonyms

  • Newportit
  • Newportita
  • Newportite
  • Ottrelit

In other languages

French
ottrelite
German
Ottrélith
Spanish
Ottrelita
Italian
Ottrélite
Arabic
أوترلايت · أوتريليت · أورلايت

Classification

Strunz
10th ed.

9.AF.85

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.85OttréliteSpecies
Dana
8th ed.

52.03.03.03

  • 52Nesosilicates Insular Sio4 Groups and O, Oh, F, H2oClass
  • 52.03Insular SiO4 Groups and O, OH, F, and H2O with cations in [6] coordination onlyType
  • 52.03.03Chloritoid groupGroup
  • 52.03.03.03OttréliteSpecies
CIM

16.16.21

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.16Aluminosilicates of MnGroup
  • 16.16.21OttréliteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1842Descloizeaux, A., Damour A.A. (1842) De l'ottrélite. Nouvelle espèce minérale. Annales des Mines: 2: 357-361.
  2. 1884Prost, E. (1884) Sur la salmite de Dumont, chloritoïde manganésifère. Annales de la Société géologique de Belgique, 11, 93.
  3. 1889Hutchings, W.M. (1889) On the Occurrence of Ottrelite in the Phyllites of North Cornwall. Geological Magazine (Decade III): 6(5): 214-220.
  4. 1898Spencer, L.J. (1898) Supplementary list of British minerals. Mineralogical Abstracts: 30: 285.
  5. 1961Halferdahl, L. B. (1961) Chloritoid: its composition, X-ray and optical properties, stability and occurrences. Journal of Petrology, 2 (1) 49-135 doi:10.1093/petrology/2.1.49DOI: 10.1093/petrology/2.1.49
