Carbonatecyanotrichite

Cu4Al2(CO3)(OH)12 · 2H2O
IMA status
  • Approved
IMA symbol
Ccya
Discovered
1963
Also known as
  • Carbonat-Cyanotrichit
  • Carbonate-cyanotrichite
  • Carbonatecyanotrichiet
  • +1 more

Where it forms, where it's found

Geological setting

secondary mineral in the oxidized zone of copper-bearing deposits

Type locality
Balasauskandyk V Deposit
  1. Shieli District
  2. Kyzylorda Region
  3. Kazakhstan

44.5333°, 67.4167°

83recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Silky
Transparency
Translucent
Colour
Pale blue
Density
2.66 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 55 – 60° · 2V calc = 60°
Refractive index
1.616 – 1.677
Surface relief
Moderate
Principal indices
nα 1.616 · nβ 1.63 · nγ 1.677
Pleochroism
Strong

X = colorless; Z = bright blue.

Dispersion
strong
Michel-Lévy diagramhighlighted lineδ = 0.0610
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]610 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation610 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 10.166(6) Å · b = 2.833(4) Å · c = 12.551(6) Å
Cell angles
β = 98.61(4) °
Ratio a:b:c
1 : 0.279 : 1.235
Type-locality form

acicular crystals to 5 mm

Comment

Z = n.d. From Grandview mine.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1715.999271.983
44.71%
29CuCopperCopper463.546254.184
41.79%
13AlAluminiumAluminium226.98253.964
8.87%
1HHydrogenHydrogen161.00816.128
2.65%
6CCarbonCarbon112.01112.011
1.98%
Total608.270100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Carbonat-Cyanotrichit
  • Carbonate-cyanotrichite
  • Carbonatecyanotrichiet
  • U227 (of Schnorrer)

In other languages

German
Carbonatcyanotrichit
Italian
Carbonatecyanotrichite · Carbonato-cianotrichite · Carbonatocianotrichite

Classification

Strunz
10th ed.

7.DE.10

  • 7SulfatesClass
  • 7.DSulfates (selenates, etc.) with additional anions, with H2ODivision
  • 7.DEWith only medium-sized cations; unclassifiedGroup
  • 7.DE.10CarbonatecyanotrichiteSpecies
Dana
8th ed.

16b.07.07.01

  • 16bHydrated Carbonates Containing Hydroxyl or HalogenClass
  • 16b.07MiscellaneousType
  • 16b.07.07— unnamed intermediate level —Group
  • 16b.07.07.01CarbonatecyanotrichiteSpecies
CIM

12.2.7

  • 12Carbonates with other anionsClass
  • 12.2Carbonates with sulphateGroup
  • 12.2.7CarbonatecyanotrichiteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. American Mineralogist: 49: 441.
  2. 1963ANKINOVICH, E. A., GEKHT, I. I. & ZAITSEVA, R. I. (1963): A new variety of cyanotrichite - carbonate-cyanotrichite. Zap. Vses. Mineral. Obshch. 92, 458-463.
  3. 1963Ankinovich E A, Gerht I I, Zaiatseva R I (1963) A new variety of cyanotrichite—carbonate-cyanotrichite. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva 92, issue 4, 458-463
  4. 1997Gröbner, J. (1997): Mineralien der Cyanotrichit-Gruppe aus Fundorten in Österreich. Mineralien-Welt 8 (3), 27-30.
  5. 2005(2005) Carbonatecyanotrichite. Handbook of Mineralogy. Mineralogical Society of America
