Cosalite

Pb2Bi2S5
IMA status
  • Approved
  • Grandfathered
IMA symbol
Cos
Discovered
1868
Also known as

Where it forms, where it's found

Geological setting

Moderate temperature hydrothermal veins, contact metasomatic deposits, epithermal replacements, pegmatites.

Type locality
Cosalá Mine
  1. Cosalá
  2. Cosalá Municipality
  3. Sinaloa
  4. Mexico

24.4083°, -106.6917°

363recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Grey
Streak
Black
Cleavage
Distinct/Good

Very rare

Fracture
Irregular/Uneven
Density
6.86 g/cm³

Optical

Pleochroism
Weak

Very weak.

Optical colour
White with trace of cream
Anisotropism
Very weak, distinct in oil
Tropism
Anisotropic
Reflectance R%
(48.2,51.4) 400, (47.0,50.3) 420, (45.9,49.5) 440, (44.9,48.7) 460, (43.9,47.9) 480, (43.0,47.1) 500, (42.2,46.4) 520, (41.6,45.9) 540, (41.1,45.5) 560, (40.8,45.3) 580, (40.5,45.2) 600, (40.4,45.2) 620, (40.2,45.2) 640, (40.1,45.2) 660, (40.1,45.2) 680, (40.0,45.1) 700
Reflected-light panel
42.5 %anisotropic · dual curve
Specimen sRGB 226, 160, 94
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Very weak, distinct in oil
Reflected colour
White with trace of cream

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 19.09 Å · b = 23.87 Å · c = 4.055 Å
Ratio a:b:c
1 : 1.250 : 0.212
Z
8
Morphology

Prismatic [001]. Frequently elongated to needle-like and capillary forms. Usually massive, also in radiating prismatic, fibrous, or feathery aggregates.

Comment

Strongly substituted (Cu, Ag, excess Bi) samples have volumes of 1830-1837 Å3 (Topa & Makovicky, 2010).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth2208.980417.960
42.10%
82PbLeadLead2207.200414.400
41.75%
16SSulfurSulfur532.060160.300
16.15%
Total992.660100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Cu
  • Fe

Synonyms

  • Bjelkeit
  • Bjelkit
  • Bjelkite
  • Bjelkitea
  • Bleibismutit
  • Bleibismutita
  • Cosaliet
  • Cuprocosalit
  • Cuprocosalita
  • Cuprocosalite
  • Retzbanyite (of Hermann)
  • Rezbanyite (of Hermann)
  • Vismutsvafladt Svafvelbly

In other languages

German
Cosalit
Italian
cosalite
Russian
Козалит

Classification

Strunz
10th ed.

2.JB.10

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.10CosaliteSpecies
Dana
8th ed.

03.05.09.01

  • 03SulfosaltsClass
  • 03.052.5 < ø < 3Type
  • 03.05.09Cosalite GroupGroup
  • 03.05.09.01CosaliteSpecies
CIM

5.6.24

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.6Sulpharsenites etc. of Pb aloneGroup
  • 5.6.24CosaliteSpecies

Group, growth & confusion

Often grow together
5 minerals

Literature, links & citation

Citations
  1. 1868Genth, F.A. (1868) Contributions to mineralogy - No. VII. American Journal of Science and Arts: 95: 305-321. (Pp. 319-320).
  2. 1874Lundström (1874) Geol. För. Förh.: 2: 178.
  3. 1874Groth (1874) 18.
  4. 1878Sjögren (1878) Geol. För. Förh.: 4: 107.
  5. 1884Hillebrand, W.F. (1884) On an interesting variety of löllingite and other minerals. American Journal of Science: 27: 343-358.
