Gustavite

AgPbBi3S6
IMA status
  • Approved
IMA symbol
Gus
Discovered
1967
IMA approved
1967
Also known as
  • Gustaviet
  • IMA1967-048

Where it forms, where it's found

Geological setting

Hydrothermal mineral, pegmatites

Type locality
Ivigtut Mine
  1. Ivigtut stock
  2. Arsuk Fjord
  3. Sermersooq
  4. Greenland

61.2061°, -48.1756°

128recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Cleavage
Imperfect/Fair

Rare, parallel to tabular faces, rarer perpendicular to tabular faces

Density
7.01 g/cm³

Optical

Pleochroism
Visible

White to grey

Optical colour
Bluish black to greyish-white
Anisotropism
Weak in air, distinct in oil bluish black to grayish white
Tropism
Anisotropic

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 13.54 Å · b = 19.44 Å · c = 4.1 Å
Ratio a:b:c
1 : 1.436 : 0.303
Z
4
Morphology

Tabular crystals, sometimes bent.

Twinning

Two twin laws found in type material. The first is very common; repeated twinning with an irregular composition plane parallel to the tabular plates. The second is uncommon; composition plane perpendicular to the tabular plates.

Type-locality form

Grains, tabular in form and sometimes slightly bent. Smaller crystals tend to be idiomorphic. Maximum grain size is 2 x 2 x 0.5 mm.

Comment

Data for synthetic gustavite. Type material appears to be monoclinic, with P21/c cell with a = 7.077 (7) Å, b = 19.566 (12) Å, c = 8.272 (8) Å and beta = 107.18 (9)° (Harris & Chen, 1975). Makovicky & Topa (2011) give, for a crystal from Rotgülden, the following unit-cell parameters (space group P21/c): a = 7.0567(14), b = 19.6905(39), c = 8.2219(16) Å, beta = 106.961(3)°, V = 1092.7(2) Å3.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth3208.980626.940
55.27%
82PbLeadLead1207.200207.200
18.26%
16SSulfurSulfur632.060192.360
16.96%
47AgSilverSilver1107.868107.868
9.51%
Total1134.368100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Sb

Synonyms

  • Gustaviet
  • IMA1967-048

In other languages

German
Gustavit · IMA 1967-048
Italian
Gustavite

Classification

Strunz
10th ed.

2.JB.40a

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.40aGustaviteSpecies
Dana
8th ed.

03.04.15.03

  • 03SulfosaltsClass
  • 03.04ø = 3Type
  • 03.04.15Lillianite Group (Orthorhombic, AmBnS6 where A=Pb, Ag, Mn and B=Sb, Bi)Group
  • 03.04.15.03GustaviteSpecies
CIM

5.7.36

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.36GustaviteSpecies

Group, growth & confusion

Often grow together
12 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1970Karup-Møller, S. (1970) Gustavite, a new sulphosalt mineral from Greenland. The Canadian Mineralogist: 10: 173-190.
  2. 1971Fleischer, Michael (1971) New Mineral Names. American Mineralogist, 56 (3-4) 631-640
  3. 1975Harris, D. C., Chen, T. T. (1975) Gustavite: two Canadian occurrences. The Canadian Mineralogist, 13 (4) 411-414
  4. 1977Makovicky, E. and Karup-Møller, S. (1977): Chemistry and crystallography of the lillianite homologous series. II. Definition of new minerals eskimoite, vikingite, ourayite and treasurite. Redefinition of schirmerite and new data on the lillianite-gustavite solid-solution series. Neues Jahrbuch für Mineralogie, Abhandlungen: 131: 56-82.
  5. 1979Karup-Møller, Sven, Makovicky, Emil (1979) On pavonite, cupropavonite, benjaminite and «oversubstituted » gustavite. Bulletin de Minéralogie, 102 (4) 351-367 doi:10.3406/bulmi.1979.7330DOI: 10.3406/bulmi.1979.7330
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Gustavite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/gustavite-1782},
  note      = {Accessed 2026-05-11}
}
