Destinezite

Fe3+2(PO4)(SO4)(OH) · 6H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Dtz
IMA approved
2002

Where it forms, where it's found

Type locality
Argenteau
  1. Visé
  2. Liège
  3. Wallonia
  4. Belgium

50.6982°, 5.6855°

29recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Yellow · brownish yellow · brown · reddish brown · greenish yellow · pale green · pale yellow · pale yellow to yellowish brown in transmitted light
Fracture
Conchoidal
Density
2.2 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 55° · 2V calc = 56°
Refractive index
1.615 – 1.665
Surface relief
Moderate
Principal indices
nα 1.615 · nβ 1.625 · nγ 1.665
Birefringence
0.050
Dispersion
r<v strong
Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.584 Å · b = 9.748 Å · c = 7.338 Å
Cell angles
α = 93.07 ° · β = 95.78 ° · γ = 105.32 °
Ratio a:b:c
1 : 1.017 : 0.766
Z
2
Morphology

Rarely microcrystalline comprised of six-sided platy crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
56.10%
26FeIronIron255.845111.690
26.11%
16SSulfurSulfur132.06032.060
7.49%
15PPhosphorusPhosphorus130.97430.974
7.24%
1HHydrogenHydrogen131.00813.104
3.06%
Total427.813100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

German
Destinezit
Italian
destinezite

Classification

Strunz
10th ed.

8.DB.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DBWith only medium-sized cations, (OH, etc.):RO4< 1:1Group
  • 8.DB.05DestineziteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1880Forir, H. (1880) Note sur la diadochite (destinézite) et la delvauxite. Annales de la Société Géologique de Belgique, 8, 151-154.
  2. 1881Forir, H. (1881) Sur quelques minéraux et fossiles trouvés dans une excursion à Argenteau. Annales de la Société Géologique de Belgique, 7, 115-123.
  3. 1881Forir, H., Jorissen, A. (1881) Sur quelques minéraux et fossiles trouvés dans une excursion à Argenteau. Bulletin de la Sociètè Belge de Gèologie, 7, 117.
  4. 1885Cesàro, G. (1885) Étude chimique et cristallographique de la destinézite (diadochite de Visé). Annales de la Société géologique de Belgique, 12, 173.
  5. 1923Veselý (1923) Bull. int. ac. Bohême, 23, 177.
