Sanjuanite

Al2(PO4)(SO4)(OH) · 9H2O
IMA status
  • Approved
IMA symbol
Sjn
Discovered
1966
IMA approved
1966
Also known as
  • IMA1966-043
  • Sanjuaniet

Where it forms, where it's found

Geological setting

Dark Carboniferous slate.

Type locality
Sierra Chica de Zonda
  1. Pocito Department
  2. San Juan Province
  3. Argentina

-31.7000°, -68.6667°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
White
Fracture
Irregular/Uneven
Density
1.94 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.484 – 1.499
Surface relief
Low
Principal indices
nα 1.484 · nγ 1.499
Dispersion
r > v to r < v strong
Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 11.314(11) Å · b = 9.018(9) Å · c = 7.376(7) Å
Cell angles
α = 93 ° · β = 95 ° · γ = 105 °
Ratio a:b:c
1 : 0.797 : 0.652
Type-locality form

Microscopic laths, parallel to divergent, fibrous, in chalk-like aggregates.

Comment

Questionable

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
67.90%
13AlAluminiumAluminium226.98253.964
12.72%
16SSulfurSulfur132.06032.060
7.56%
15PPhosphorusPhosphorus130.97430.974
7.30%
1HHydrogenHydrogen191.00819.152
4.52%
Total424.132100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1966-043
  • Sanjuaniet

In other languages

German
IMA 1966-043 · Sanjuanit
Italian
Sanjuanite

Classification

Strunz
10th ed.

8.DB.30

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DBWith only medium-sized cations, (OH, etc.):RO4< 1:1Group
  • 8.DB.30SanjuaniteSpecies
Dana
8th ed.

43.05.01.03

  • 43Compound Phosphates, Etc.Class
  • 43.05Hydrated Compound Phosphates, etc·, Containing Hydroxyl or HalogenType
  • 43.05.01Sarmientite GroupGroup
  • 43.05.01.03SanjuaniteSpecies
CIM

22.3.11

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.3Phosphates, arsenates or vanadates with sulphatesGroup
  • 22.3.11SanjuaniteSpecies

Group, growth & confusion

In the same group
3 members

Literature, links & citation

Citations
  1. 1968de Abeledo, M. E. J., Angelelli, V., de Benyacar, M. A. R., Gordillo, C. (1968) Sanjuanite, a new hydrated basic sulfate-phosphate of aluminum. American Mineralogist, 53 (1-2) 1-8
  2. 1989De Bruiyn, H., Beukes, G. J., Van Der Westhuizen, W. A., Tordiffe, E. A. W. (1989) Unit cell dimensions of the hydrated aluminium phosphate–sulphate minerals sanjuanite, kribergite, and hotsonite. Mineralogical Magazine, 53 (371) 385-386 doi:10.1180/minmag.1989.053.371.17 DOI: 10.1180/minmag.1989.053.371.17
  3. 2005(2005) Sanjuanite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2010Colombo, F., Rius, J., Panunzio, E.V. (2010) Crystal structure solution of the mineral sanjuanite from laboratory powder diffraction data. 26th European Crystallographic Meeting 29 August- 2 September 2010, Darmstadt, Germany, Abstract, 2010, MS16-P13.
  5. 2011Colombo, F., Rius, J., Pannunzio-Miner, E. V., Pedregosa, J. C., Cami, G. E., Carbonio, R. E. (2011) Sanjuanite: Ab Initio crystal-structure solution from laboratory powder-diffraction data, complemented by FTIR spectroscopy and DT-TG analyses. The Canadian Mineralogist, 49 (3) 835-847 doi:10.3749/canmin.49.3.835 DOI: 10.3749/canmin.49.3.835
