Eskimoite

Ag7Pb10Bi15S36
IMA status
  • Approved
IMA symbol
Ekm
Discovered
1977
Also known as
  • Eskimoiet
  • IMA1976-005

Where it forms, where it's found

Geological setting

Cryolite deposit

Type locality
Ivigtut Mine
  1. Ivigtut stock
  2. Arsuk Fjord
  3. Sermersooq
  4. Greenland

61.2061°, -48.1756°

24recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Density
7.12 g/cm³

Optical

Pleochroism
Weak

absent to weak in oil, absent in air.

Optical colour
Galena white
Anisotropism
Distinct to strong , light gray to steel bluish black
Tropism
Anisotropic
Reflectance R%
(45.4,48.2) 481, (43.7,46.5) 546, (42.8,45.6) 589, (42.0,44.8) 644
Reflected-light panel
43.5 %anisotropic · dual curve
Specimen sRGB 230, 164, 93
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Distinct to strong , light gray to steel bluish black
Reflected colour
Galena white

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 30.194(8) Å · b = 4.100(5) Å · c = 13.495(5) Å
Cell angles
β = 93.35(1) °
Ratio a:b:c
1 : 0.136 : 0.447
Z
1
Morphology

Lamellar grains.

Twinning

On (010), twin lamellae parallel to [001] often present

Comment

Original description used a B-centred, non-standard cell setting (gamma = monoclinic angle).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
83BiBismuthBismuth15208.9803134.700
44.05%
82PbLeadLead10207.2002072.000
29.12%
16SSulfurSulfur3632.0601154.160
16.22%
47AgSilverSilver7107.868755.076
10.61%
Total7115.936100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Cu

Synonyms

  • Eskimoiet
  • IMA1976-005

In other languages

German
Eskimoit · IMA 1976-005
Italian
Eskimoite

Classification

Strunz
10th ed.

2.JB.40b

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.40bEskimoiteSpecies
Dana
8th ed.

03.06.02.01

  • 03SulfosaltsClass
  • 03.062 < ø < 2.49Type
  • 03.06.02— unnamed intermediate level —Group
  • 03.06.02.01EskimoiteSpecies
CIM

5.7.26

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.7Sulpharsenites etc. of Pb and other metalsGroup
  • 5.7.26EskimoiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1977Makovicky, E. and Karup-Møller, S. (1977): Chemistry and crystallography of the lillianite homologous series. II. Definition of new minerals eskimoite, vikingite, ourayite and treasurite. Redefinition of schirmerite and new data on the lillianite-gustavite solid-solution series. Neues Jahrbuch für Mineralogie, Abhandlungen: 131: 56-82.
  2. 1979American Mineralogist (1979): 64: 243-244.
  3. 1994Ertl, A., Libowitzky, E. & Pertlik, F. (1994): Chemische und röntgenographische Untersuchungen an Eskimoit (~Ag7Pb10Bi15S36) und Heyrovskyit (~AgPb10Bi5S18) vom „Rauriser Goldberg“, Hüttwinkeltal, Land Salzburg. Mitt. Österr. Mineral. Ges., 139, 135-142.
  4. 2005(2005) Eskimoite. Handbook of Mineralogy. Mineralogical Society of America
