Heyrovskýite

Pb6Bi2S9
IMA status
  • Approved
IMA symbol
Hyv
Also known as
  • Heyrovskit
  • Heyrovskita
  • Heyrovskite
  • +2 more

Where it forms, where it's found

Geological setting

Hydrothermal; high-temperature quartz veins.

Type locality
Hůrky
  1. Čistá ring
  2. Čistá
  3. Rakovník District
  4. Central Bohemian Region
  5. Czech Republic

50.0167°, 13.5667°

62recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Colour
Tin white
Streak
Greyish black
Tenacity
brittle
Cleavage
Poor/Indistinct
Density
7.17 g/cm³

Optical

Anisotropism
Strong, dark gray to white in air, grayish-white to brownish in oil.
Bireflectance
Weak in air with color white to light gray, distinct bireflectance in oil, white, to grayish white.
Tropism
Anisotropic
Reflectance R%
(43.3,47.3) 470, (40.6,44.6) 546, (39.8,43.9) 589, (39.6,43.7) 650
Reflected-light panel
40.8 %anisotropic · dual curve
Specimen sRGB 224, 159, 92
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Weak in air with color white to light gray, distinct bireflectance in oil, white, to grayish white.
Anisotropism
Strong, dark gray to white in air, grayish-white to brownish in oil.

Crystallography

Crystal system
Orthorhombic
Space group
Cccm
Cell parameters
a = 4.1457(3) Å · b = 13.7421(5) Å · c = 31.5005(12) Å
Ratio a:b:c
1 : 3.315 : 7.598
Unit cell volume
1794.6 ų
Z
4
Type-locality form

Acicular crystals less than 20 mm long and 0.1 to 0.5 mm thick, and in masses to 2 mm.

Comment

Cell parameters from Pervukhina et al. (2012).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead6207.2001243.200
63.76%
83BiBismuthBismuth2208.980417.960
21.44%
16SSulfurSulfur932.060288.540
14.80%
Total1949.700100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Heyrovskit
  • Heyrovskita
  • Heyrovskite
  • Heyrovskýiet
  • IMA1970-022

In other languages

German
Heyrovskýit · IMA 1970-022
Italian
Heyrovskýite

Classification

Strunz
10th ed.

2.JB.40b

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.40bHeyrovskýiteSpecies
Dana
8th ed.

03.03.03.01

  • 03SulfosaltsClass
  • 03.033 <ø < 4Type
  • 03.03.03— unnamed intermediate level —Group
  • 03.03.03.01HeyrovskýiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1971Klomínský, K., Rieder, M., Kieft, C., Mráz, L. (1971) Heyrovskýite, 6(Pb0.86Bi0.08(Ag,Cu)0.04)S·Bi2S3, from Hurky, Czechoslovakia, a new mineral of genetic interest. Mineralium Deposita: 6: 133-147.
  2. 1972Fleischer, Michael (1972) New Mineral Names. American Mineralogist, 57 (1-2) 325-329
  3. 1974Takéuchi, Y., Takagi, J. (1974) The structure of heyrovskyite (6PbS·Bi2S3). Proceedings of the Japan Academy: 50: 76-79.
  4. 1981Karup-Møller, S., Makovicky, E. (1981) Ag- and Bi-rich heyrovskyite from the Bi–W–Mo mineralization at Castlegar, British Columbia. The Canadian Mineralogist: 19: 349-353.
  5. 1983Mumme, W.G., Niedermayr, G., Kelly, P.R., Paar, W.H. (1983): Aschamalmite, Pb5.92Bi2.06S9, from Untersulzbach Valley in Salzburg, Austria - “monoclinic heyrovskyite”. Neues Jahrbuch für Mineralogie, Monatshefte: 1983: 433-444.
