Ferrobustamite

CaFe2+Si2O6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Fbst
Discovered
1973
Also known as
  • Ferrobustamiet
  • Vogtit
  • Vogtita
  • +1 more

Where it forms, where it's found

Geological setting

chert nodules in a skarn in dolostone

Type locality
Camas Malag
  1. Torrin
  2. Broadford
  3. Isle of Skye
  4. Eilean á Chèo
  5. Highland
  6. Scotland
  7. UK

57.2009°, -5.9987°

16recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colorless · pink to brown.
Cleavage
Perfect

(100), perfect; (110), (110), good

Density
3.09 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60°
Refractive index
1.64 – 1.653
Surface relief
Moderate
Principal indices
nα 1.64 · nγ 1.653
Dispersion
relatively weak
Notes

X' Λ c = 44° in section perpendicular to the zone of cleavages.

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 7.862 Å · b = 7.253 Å · c = 13.967 Å
Cell angles
α = 89.73 ° · β = 95.47 ° · γ = 103.48 °
Ratio a:b:c
1 : 0.923 : 1.777
Z
6
Twinning

Simple twins on (100).

Comment

Space Group: A_1

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
38.69%
14SiSiliconSilicon228.08556.170
22.64%
26FeIronIron155.84555.845
22.51%
20CaCalciumCalcium140.07840.078
16.16%
Total248.087100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Mg

Synonyms

  • Ferrobustamiet
  • Vogtit
  • Vogtita
  • Vogtite

In other languages

German
Ferrobustamit
Italian
Ferrobustamite
Chinese
铁硅灰石

Classification

Strunz
10th ed.

9.DG.05

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.05FerrobustamiteSpecies
Dana
8th ed.

65.02.01.03

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.02Single-Width Unbranched Chains, W=1 with chains P=3Type
  • 65.02.01Wollastonite groupGroup
  • 65.02.01.03FerrobustamiteSpecies
CIM

14.18.17

  • 14Silicates not Containing AluminumClass
  • 14.18Silicates of Mn and Na, K, Mg, Ca or FeGroup
  • 14.18.17FerrobustamiteSpecies

Group, growth & confusion

Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1937Tilley, C. E. (1937) Wollastonite solid solutions from Scawt Hill, Co. Antrim. Mineralogical Magazine and Journal of the Mineralogical Society, 24 (158) 569-572 doi:10.1180/minmag.1937.024.158.03 DOI: 10.1180/minmag.1937.024.158.03
  2. 1948Tilley, C.E. (1948) On iron-wollastonites in contact-skarns: an example from Skye. American Mineralogist, 33 (11-12) 736-738
  3. 1973Rapoport, P.A., Burnham, C.W. (1973) Ferrobustamite: The crystal structures of two Ca,Fe bustamite-type pyroxenoids. Zeitschrift für Kristallographie: 138: 419-438.
  4. 1973Shimazaki, H., Yamanaka, T. (1973) Iron-wollastonite from skarns and its stability relation in the CaSiO3-CaFeSi2O6 join. Geochemical Journal: 7: 67-79.
  5. 1974Fleischer, Michael (1974) New mineral names. American Mineralogist, 59 (5-6). 632-633
