Ferrowodginite

Fe2+Sn4+Ta2O8
IMA status
  • Approved
IMA symbol
Fwdg
Discovered
1992
Also known as
  • Ferrowodginiet
  • IMA1984-006

Where it forms, where it's found

Type locality
Sukula Pegmatites
  1. Tammela
  2. Kanta-Häme
  3. Finland

60.7705°, 23.5943°

22recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Dark brown to black
Streak
Dark brown
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
7.02 g/cm³

Optical

Optical type
Biaxial
Anisotropism
noted
Tropism
Anisotropic
UV response
Non-fluorescent
Notes

α = > 2.0 β = > 2.0 γ = > 2.0

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 9.415(7) Å · b = 11.442(6) Å · c = 5.103(4) Å
Cell angles
β = 90.8 °
Ratio a:b:c
1 : 1.215 : 0.542
Z
4
Twinning

Polysynthetic on (100).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
73TaTantalumTantalum2180.948361.896
54.47%
8OOxygenOxygen815.999127.992
19.26%
50SnTinTin1118.710118.710
17.87%
26FeIronIron155.84555.845
8.40%
Total664.443100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Mn
  • Ti
  • Nb

Synonyms

  • Ferrowodginiet
  • IMA1984-006

In other languages

German
Ferrowodginit · IMA 1984-006
Italian
ferrowodginite

Classification

Strunz
10th ed.

4.DB.40

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DBWith medium-sized cations; chains of edge-sharing octahedraGroup
  • 4.DB.40FerrowodginiteSpecies
Dana
8th ed.

08.01.08.02

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.01ABO4Type
  • 08.01.08Wodginite GroupGroup
  • 08.01.08.02FerrowodginiteSpecies

Group, growth & confusion

In the same group
7 members

Literature, links & citation

Citations
  1. 1992Ercit, T. Scott, Černý, Petr, Hawthorne, Frank C. (1992) The wodginite group. III. Classification and new species. The Canadian Mineralogist, 30 (3) 633-638
  2. 2005(2005) Ferrowodginite. Handbook of Mineralogy. Mineralogical Society of America
