Florencite-(Nd)

NdAl3(PO4)2(OH)6
IMA status
  • Approved
IMA symbol
Flo-Nd
Also known as
  • Florenciet-(Nd)

Where it forms, where it's found

Geological setting

In the weathered zone, on fracture surfaces, in chert.

Type locality
Sausalito Road Quarry
  1. Sausalito
  2. Marin County
  3. California
  4. USA

37.8402°, -122.4806°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Moderate brown
Density
3.70 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.72 – 1.73
Surface relief
High
Principal indices
nω 1.72 · nε 1.73
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 6.992(1) Å · c = 16.454(7) Å
Z
3
Morphology

As powdery aggregates.

Type-locality form

Pulverulent earthy material in which individual crystals cannot be distinguished with a microscope.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
43.31%
60NdNeodymiumNeodymium1144.242144.242
27.89%
13AlAluminiumAluminium326.98280.946
15.65%
15PPhosphorusPhosphorus230.97461.948
11.98%
1HHydrogenHydrogen61.0086.048
1.17%
Total517.170100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Florenciet-(Nd)

In other languages

German
Florencit-(Nd)
Italian
Florencite- · Florencite-(Nd)
Chinese
磷钕铝石

Classification

Strunz
10th ed.

8.BL.13

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.13Florencite-(Nd)Species
Dana
8th ed.

41.05.10.04

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.05(AB)2(XO4)ZqType
  • 41.05.10Dussertite GroupGroup
  • 41.05.10.04Florencite-(Nd)Species
CIM

19.9.12

  • 19PhosphatesClass
  • 19.9Phosphates of rare earths and ScGroup
  • 19.9.12Florencite-(Nd)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1971Milton, Daniel J., Bastron, Harry (1971) Churchite and Florencite-(Nd) from Sausalito, California. The Mineralogical Record, 2 (4) 166-168
  2. 1986Fitzpatrick, Joan (1986) Powder X-Ray Diffraction Data of Florencite-(Nd). Powder Diffraction, 1 (4). 330 doi:10.1017/s0885715600012021DOI: 10.1017/s0885715600012021
  3. 1990Kato, T. (1990) The crystal structure of florencite. Neues Jahrbuch für Mineralogie, Monatshefte, 1990, 227-231.
  4. 2005(2005) Florencite-(Nd). Handbook of Mineralogy. Mineralogical Society of America
