Goyazite

SrAl3(PO4)(PO3OH)(OH)6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Goy
Discovered
1884
Also known as
  • Bowmanit
  • Bowmanita
  • Bowmanite
  • +11 more

Where it forms, where it's found

Geological setting

Placer nodules

Granitic pegmatites; hydrothermal argillic alteration zones; in kaolinitic claystones derived from air-fall volcanic tuffs; sedimentary phosphate deposits, carbonatites; detrital deposits, including diamantiferous sands.

Type locality
Diamantina
  1. Minas Gerais
  2. Brazil

-18.2458°, -43.6000°

209recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Resinous or pearly
Transparency
Transparent · Translucent
Colour
White · yellow · honey-yellow · pink · lilac · orange or colourless · colourless in transmitted light.
Tenacity
very brittle
Cleavage
Perfect

On (0001), perfect.

Density
3.26 g/cm³

Optical

Optical type
Uniaxial (+) · 2V measured = 30°
Refractive index
1.62 – 1.651
Surface relief
Moderate
Principal indices
nω 1.620 – 1.635 · nε 1.630 – 1.651
Birefringence
0.013
Pleochroism
Weak

Thick grains (Ukraine): O = Light pink E = Pale Yellow, Pale green

UV response
Not Fluorescent
Notes

May be anomously biaxial, sectored.

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 7.015 Å · c = 16.558 Å
Z
3
Morphology

Crystals rhombohedral, up to 2 cm, pseudocubic or flattened on (0001), with (1012) striated (?) [0001], (2021), (0111), small (0001), rarely paper thin plates with large (0001); may be composite; massive, in detrital pebbles (favas) and grains.

Type-locality form

Small rounded grains 1-5 mm in diameter.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
48.53%
38SrStrontiumStrontium187.62087.620
18.98%
13AlAluminiumAluminium326.98280.946
17.54%
15PPhosphorusPhosphorus230.97461.948
13.42%
1HHydrogenHydrogen71.0087.056
1.53%
Total461.556100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ba
  • F

Synonyms

  • Bowmanit
  • Bowmanita
  • Bowmanite
  • Goyaziet
  • Goyzait
  • Goyzaita
  • Goyzaite
  • Hamlinit
  • Hamlinita
  • Hamlinite
  • Lusungite
  • Strontiohitchcockit
  • Strontiohitchcockita
  • Strontiohitchcockite

In other languages

French
Goyazite
German
Goyazit
Spanish
goyazita
Italian
Goyazite

Classification

Strunz
10th ed.

8.BL.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.10GoyaziteSpecies
Dana
8th ed.

42.07.03.03

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.03Crandallite GroupGroup
  • 42.07.03.03GoyaziteSpecies
CIM

19.5.3

  • 19PhosphatesClass
  • 19.5Phosphates of Sr and BaGroup
  • 19.5.3GoyaziteSpecies

Group, growth & confusion

Often grow together
7 minerals
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1884Damour, Augustin-Alexis (1884) Note sur un nouveau phosphate d'alumine et de chaux des terrains diamantifères [goyazite]. Bulletin de Minéralogie, 7 (6) 204-205 doi:10.3406/bulmi.1884.1862 DOI: 10.3406/bulmi.1884.1862
  2. 1890Hidden, W.E. and Penfield, S.L. (1890) On Hamlinite a new rhombohedral mineral from the Herderite Locality at Stoneham, Maine. American Journal of Science, 3rd Series, 39, 511-513.
  3. 1897Penfield, S.L. (1897) On the chemical composition of hamlinite and its occurrence with bertrandite at Oxford County, Maine. American Journal of Science: 4(22): 313-316.
  4. 1897Penfleld, S. L. (1897) Ueber die chemische Zusammensetzung des Hamlinits und sein Vorkommen mit Bertrandit in Oxford County, Maine. Zeitschrift für Kristallographie, 28 (1-6). 588-591 doi:10.1524/zkri.1897.28.1.588DOI: 10.1524/zkri.1897.28.1.588
  5. 1905Solly, R. H. (1905) Some new minerals from the Binnenthal, Switzerland. Mineralogical Magazine and Journal of the Mineralogical Society, 14 (64) 72-82 doi:10.1180/minmag.1905.014.64.03 DOI: 10.1180/minmag.1905.014.64.03
