Gorceixite

BaAl3(PO4)(PO3OH)(OH)6
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gcx
Discovered
1906
Also known as
  • Bariohitchcockit
  • Bariohitchcockita
  • Bariohitchcockite
  • +7 more

Where it forms, where it's found

Geological setting

Stream pebbles "favas".

Granite pegmatites,sedimentary phosphates beds, carbonatites, iron ore deposits, polymetallic veins, baryte-fluorite veins.

Type locality
Ouro Preto
  1. Minas Gerais
  2. Brazil
128recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · colorless · green or brown · may be mottled · colourless in transmitted light..
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Conchoidal · Sub-Conchoidal
Density
3.036 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.61 – 1.625
Surface relief
Moderate
Principal indices
nω 1.610 – 1.618 · nε 1.620 – 1.625
Birefringence
0.008
Michel-Lévy diagramhighlighted lineδ = 0.0080
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]80 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation80 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
Cm
Cell parameters
a = 12.18 Å · b = 7.03 Å · c = 7.03 Å
Cell angles
β = 125.3 °
Ratio a:b:c
1 : 0.577 : 0.577
Z
2
Morphology

Pseudo-cubic or pseudorhombohedral. Grains and pebbles (favas) that are, in part, microcrystalline.

Type-locality form

Rounded nodules in sediment.

Comment

Pseudorhombohedral. Some samples are apparently rhombohedral, however (a = 7.0538(3), c = 17.2746(6) A, Z = 3, V = 744.4(2) A3; Dzikowski et al., 2006).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
43.81%
56BaBariumBarium1137.327137.327
26.86%
13AlAluminiumAluminium326.98280.946
15.83%
15PPhosphorusPhosphorus230.97461.948
12.12%
1HHydrogenHydrogen71.0087.056
1.38%
Total511.263100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Bariohitchcockit
  • Bariohitchcockita
  • Bariohitchcockite
  • Ferrazite
  • Geraesit
  • Geraesita
  • Geraesite
  • Gorceixiet
  • Gosseixita
  • Gosseixite

In other languages

French
Bariohitchcockite · Ferrazite · Geraesite · Gorceixite · Gosseixite
German
Bariohitchcockit · Ferrazit · Geraesit · Gorceixit · Gosseixit
Italian
Ferrazite · Gorceixite
Chinese
磷钡铝石

Classification

Strunz
10th ed.

8.BL.10

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BLWith medium-sized and large cations, (OH, etc.):RO4 = 3:1Group
  • 8.BL.10GorceixiteSpecies
Dana
8th ed.

42.07.03.02

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.03Crandallite GroupGroup
  • 42.07.03.02GorceixiteSpecies
CIM

19.5.10

  • 19PhosphatesClass
  • 19.5Phosphates of Sr and BaGroup
  • 19.5.10GorceixiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1906Hussak, E. (1906) Über die sogenannten “phosphat-favas” der diamantführenden Sande Brasiliens. Tschermaks Mineralogische und Petrographische Mitteilungen: 25: 335-344.
  2. 1907Gaubert, P. (1907) Sur les indices de réfraction de quelques minéraux. Bulletin de la Société française de Minéralogie: 30(4): 104-108 (108).
  3. 1916Farrington (1916) American Journal of Science: 41: 357.
  4. 1916Farrington, O.C. (1916) Studies of Brazilian favas. American Journal of Science: 244: 355-360.
  5. 1941Beard, E.H. (1941) Recent discoveries of gorceixite. Bulletin of the Imperial Institute, London: 39: 160.
