Fluoro-leakeite

NaNa2(Mg2Al2Li)Si8O22F2
IMA status
  • Approved
IMA symbol
Fllk
IMA approved
2009
Also known as
  • Fluoro-aluminoleakeite
  • Fluoro-leakeiet
  • IMA2009-012

Where it forms, where it's found

Geological setting

Occurs in a proterozoic alkaline intrusion that mainly comprises a fine-grained schistose agpaitic nepheline-syenite (grennaite).

Type locality
Norra Kärr
  1. Gränna
  2. Jönköping
  3. Jönköping County
  4. Sweden

58.1022°, 14.5658°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Light greenish-blue
Streak
Greenish-blue
Cleavage
Perfect

Perfect (110)

Fracture
Splintery
Density
3.14 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 98.0° · 2V calc = 95.5°
Refractive index
1.632 – 1.643
Surface relief
Moderate
Principal indices
nα 1.632 · nβ 1.638 · nγ 1.643
Pleochroism
Visible

X = pale green, Y = dark green, Z = pale green.

Extinction
X ∧ a = 62.9º (in b obtuse); Y = b.
UV response
Not fluorescent.
Michel-Lévy diagramhighlighted lineδ = 0.0110
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]110 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation110 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.7043(5) Å · b = 17.7341(8) Å · c = 5.2833(3) Å
Cell angles
β = 104.067(4) °
Ratio a:b:c
1 : 1.827 : 0.544
Z
2
Morphology

Prismatic crystals.

Parting
No observable parting
Type-locality form

As isolated prismatic crystals 0.10-2 mm long in a syenitic matrix.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2215.999351.978
44.38%
14SiSiliconSilicon828.085224.680
28.33%
11NaSodiumSodium322.99068.970
8.70%
13AlAluminiumAluminium226.98253.964
6.80%
12MgMagnesiumMagnesium224.30548.610
6.13%
9FFluorineFluorine218.99837.996
4.79%
3LiLithiumLithium16.9406.940
0.87%
Total793.138100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Fluoro-aluminoleakeite
  • Fluoro-leakeiet
  • IMA2009-012

In other languages

German
Fluoro-Leakeit · IMA 2009-012
Italian
fluoro-aluminoleakeite · fluoro-leakeite

Classification

Strunz
10th ed.

9.DE.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.25Fluoro-leakeiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. IMA Approvals - June 2009
  2. 2009Oberti, R., Cámaraite, F., Hawthorne, F. C., Ball, N. A. (2009) Fluoro-aluminoleakeite, NaNa2(Mg2Al2Li)Si8O22F2, a new mineral of the amphibole group from Norra Kärr, Sweden: description and crystal structure. Mineralogical Magazine, 73 (5) 817-824 doi:10.1180/minmag.2009.073.5.817 DOI: 10.1180/minmag.2009.073.5.817
  3. 2010Cámara, F., Hawthorne, F. C., Ball, N. A., Bekenova, G., Stepanov, A. V., Kotel'nikov, P. E. (2010) Fluoroleakeite, NaNa2(Mg2Fe3+2Li)Si8O22F2, a new mineral of the amphibole group from the Verkhnee Espe deposit, Akjailyautas Mountains, Eastern Kazakhstan District, Kazakhstan: description and crystal structure. Mineralogical Magazine, 74 (3) 521-528 doi:10.1180/minmag.2010.074.3.521 DOI: 10.1180/minmag.2010.074.3.521
  4. 2011(2011) Fluoro-leakeite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2012Hawthorne, F. C., Oberti, R., Harlow, G. E., Maresch, W. V., Martin, R. F., Schumacher, J. C., Welch, M. D. (2012) Nomenclature of the amphibole supergroup. American Mineralogist, 97 (11) 2031-2048 doi:10.2138/am.2012.4276 DOI: 10.2138/am.2012.4276
