Gibbsite

Al(OH)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gbs
Discovered
1822
Also known as
  • b-Kliachita
  • b-Kliachite
  • Claussenit
  • +9 more

Where it forms, where it's found

Geological setting

Bog iron deposit.

Type locality
Richmond
  1. Berkshire County
  2. Massachusetts
  3. USA

42.3731°, -73.3681°

478recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · light gray · light green · reddish white · reddish yellow (impure) · blue · turquoise · purple

Ideally white; colored by mineral mixtures

Streak
White
Tenacity
brittle
Cleavage
Perfect

(001), but rarely observed because of its fine-grained nature.

Fracture
Irregular/Uneven
Density
2.38 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 5°
Refractive index
1.568 – 1.587
Surface relief
Moderate
Principal indices
nα 1.568 – 1.57 · nβ 1.568 – 1.57 · nγ 1.586 – 1.587
Birefringence
0.018
Pleochroism
Non-pleochroic
Dispersion
r > v or r < v
Extinction
Y^c = 69° X = b
UV response
Yellowish white to creamy white in SW and LW. Also green to greenish white in SW.
Michel-Lévy diagramhighlighted lineδ = 0.0180
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]180 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation180 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 8.684 Å · b = 5.078(1) Å · c = 9.736(2) Å
Cell angles
β = 94.54(1) °
Ratio a:b:c
1 : 0.585 : 1.121
Z
8
Morphology

Almost always earthy and nodular; rare crystals tabular (001), with (100) and (110} usually well-developed.

Twinning

1. About [130] as twin axis, very common. 2. On (001), common, usually in combination with other twin laws. 3. On (100), uncommon. 4. Rare on (110)

Comment

Space group P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen315.99947.997
61.53%
13AlAluminiumAluminium126.98226.982
34.59%
1HHydrogenHydrogen31.0083.024
3.88%
Total78.003100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Ga

Synonyms

  • b-Kliachita
  • b-Kliachite
  • Claussenit
  • Claussenita
  • Claussenite
  • Gibbsite (of Torrey)
  • Gibbsitogelit
  • Gibbsitogelita
  • Gibbsitogelite
  • Hydrargillite (of Cleaveland)
  • Wavellite (of Dewey)
  • Zirlite

In other languages

French
Beta-kliachite · Claussenite · Gibbsite · Gibbsitogelite · Hydrargyllite · Zirlite
German
Gibbsit · Hydragillit · Hydrargillit
Spanish
Claussenita · Gibbsita · Gibbsitogelita · Hidrargilita
Italian
Gibbsite · Idrargillite
Portuguese
gibbsita · Gibbsite
Japanese
ギブス石
Chinese
三水铝石
Russian
Гиббсит · Гидраргиллит
Arabic
الجبسيت · جبسيت

Classification

Strunz
10th ed.

4.FE.10

  • 4OxidesClass
  • 4.FHydroxides (without V or U)Division
  • 4.FEHydroxides with OH, without H2O; sheets of edge-sharing octahedraGroup
  • 4.FE.10GibbsiteSpecies
Dana
8th ed.

06.03.01.01

  • 06Hydroxides and Oxides Containing HydroxylClass
  • 06.03X(OH)3Type
  • 06.03.01— unnamed intermediate level —Group
  • 06.03.01.01GibbsiteSpecies
CIM

7.6.4

  • 7Oxides and HydroxidesClass
  • 7.6Oxides of AlGroup
  • 7.6.4GibbsiteSpecies

Group, growth & confusion

Often grow together
4 minerals
Commonly confused with
3 minerals

Literature, links & citation

Citations
  1. 1820Silliman, Benjamin (1820) Wavellite?. The American Journal Of Science, S. 1 Vol. 2. 249
  2. 1822Torrey, J. (1822) Description and analysis of gibbsite, a new mineral. The New-York Medical and Physical Journal: 1: 68-73.
  3. 1839Rose, Gustav (1839) Beschreibung einiger neuen Mineralien des Urals. Annalen der Physik und Chemie, 124. 551-573 doi:10.1002/andp.18391241205DOI: 10.1002/andp.18391241205
  4. 1849Silliman Jr., B. (1849) On Gibbsite and Allophane, from Richmond, Mass. American Journal of Science and Arts: 7(21): 411.
  5. 1878Jannettaz, É. (1878) Gibbsite et Beauxite de la Guyane française. Bulletin de Minéralogie: 1(4): 70-71.
