Hambergite

Be2(BO3)(OH)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Hb
Discovered
1890
Also known as
  • Hamburgite

Where it forms, where it's found

Geological setting

Syenite pegmatite.

Alkali-rich pegmatites (Madagascar); gem gravels (Kashmir).

Type locality
Salbutangen
  1. Helgeroa
  2. Larvik Commune
  3. Vestfold
  4. Norway
76recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789107.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · greyish · yellowish · colourless in transmitted light
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (010); on (100) good.

Density
2.347 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 87°
Refractive index
1.554 – 1.631
Surface relief
Moderate
Principal indices
nα 1.554 – 1.56 · nβ 1.587 – 1.591 · nγ 1.628 – 1.631
Dispersion
weak r > v
Michel-Lévy diagramhighlighted lineδ = 0.0725
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]725 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation725 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#61
Cell parameters
a = 9.762(2) Å · b = 12.201(2) Å · c = 4.430(1) Å
Ratio a:b:c
1 : 1.250 : 0.454
Unit cell volume
527.6 ų
Z
8
Morphology

Crystals prismatic [001], frequently flattened (100). (100) striated [001] with dull and etched terminal faces (large crystals).

Twinning

Twin and composition plane (110).

Type-locality form

A single crystal 3.5x1.5 cm.

Comment

Cell parameters from Gatta et al (2012).

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen415.99963.996
68.20%
4BeBerylliumBeryllium29.01218.024
19.21%
5BBoronBoron110.81010.810
11.52%
1HHydrogenHydrogen11.0081.008
1.07%
Total93.838100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hamburgite

In other languages

French
Hambergite
German
Hambergit
Spanish
Hambergita
Italian
Hambergite
Japanese
ハンベルジャイト
Chinese
硼铍石
Russian
Гамбергит

Classification

Strunz
10th ed.

6.AB.05

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.ABBO3, with additional anions; 1(D) + OH, etc.Group
  • 6.AB.05HambergiteSpecies
Dana
8th ed.

25.01.01.01

  • 25Anhydrous Borates Containing Hydroxyl or HalogenClass
  • 25.01MonoboratesType
  • 25.01.01— unnamed intermediate level —Group
  • 25.01.01.01HambergiteSpecies
CIM

9.2.1

  • 9BoratesClass
  • 9.2Borates of Be and MgGroup
  • 9.2.1HambergiteSpecies

Group, growth & confusion

Often grow together
3 minerals

Literature, links & citation

Citations
  1. (1911): Zeitschrift für Kristallographie, Mineralogie und Petrographie: 50: 596–597.
  2. 1890Brøgger, Waldemar Christofer (1890) Die Mineralien der Syenitpegmatitgänge der südnorwegischen Augit- und Nephelinsyenite. Zeitschrift für Krystallographie und Mineralogie, 16 (1). 1-893
  3. 1890Bäckström (1890) Bihang KVAH Bd. 15:2, pp.23-24
  4. 1909Lacroix, Alfred (1909) Sur la hambergite de Madagascar. Bulletin de Minéralogie, 32 (7) 320-324 doi:10.3406/bulmi.1909.3373DOI: 10.3406/bulmi.1909.3373
  5. 1910Lacroix, Alfred (1910) Nouvelles observations sur les minéraux des pegmatites de Madagascar. Bulletin de Minéralogie, 33 (1) 37-53 doi:10.3406/bulmi.1910.3399DOI: 10.3406/bulmi.1910.3399
