Novgorodovaite

Ca2(C2O4)Cl2 · 2H2O
IMA status
  • Approved
IMA symbol
Nov
IMA approved
2000
Also known as
  • IMA2000-039
  • Novgorodovaiet

Where it forms, where it's found

Geological setting

in a salt dome, observed in a drill core sample from 850 – 900 m depth

Type locality
Chelkar salt dome
  1. Aksai Valley
  2. Terekti District
  3. West Kazakhstan Region
  4. Kazakhstan

50.4667°, 51.6833°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colourless
Streak
white
Tenacity
brittle
Cleavage
Distinct/Good

Good on (100) and (010)

Fracture
Irregular/Uneven · Conchoidal
Density
2.38 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 88° · 2V calc = 87°
Refractive index
1.565 – 1.725
Surface relief
Moderate
Principal indices
nα 1.565 · nβ 1.645 · nγ 1.725
Pleochroism
Non-pleochroic
UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.1600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1600 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1600 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 6.936(3) Å · b = 7.382(3) Å · c = 7.443(3) Å
Cell angles
β = 94.3 ° · γ = 1 °
Ratio a:b:c
1 : 1.064 : 1.073
Unit cell volume
380.02 ų
Z
2
Morphology

aggregates to 3 cm of grains to 7 mm

Type-locality form

grains up to 7 mm in size

Comment

Space Group: I2/m

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
34.89%
20CaCalciumCalcium240.07880.156
29.14%
17ClChlorineChlorine235.45070.900
25.77%
6CCarbonCarbon212.01124.022
8.73%
1HHydrogenHydrogen41.0084.032
1.47%
Total275.104100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2000-039
  • Novgorodovaiet

In other languages

German
IMA 2000-039 · Novgorodovait
Italian
Novgorodovaite

Classification

Strunz
10th ed.

10.AB.80

  • 10Organic CompoundsClass
  • 10.ASalts of organic acidsDivision
  • 10.ABOxalatesGroup
  • 10.AB.80NovgorodovaiteSpecies

Group, growth & confusion

Often grow together
6 minerals

Literature, links & citation

Citations
  1. 2001Chukanov, N.V., D.I. Belakovskii, R.K. Rastsvetaeva, O.V. Karimova, A.E. Zadov (2001) Novgorodovaite Ca2(C2O4)Cl2·2H2O, a new mineral. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 130(4): 32-35.
  2. 2001Rastsvetaeva, R.K., Chukanov, N.V., Nekrasov, Y.V. (2001) Crystal structure of novgorodovaite, Ca2(C2O4)Cl2·2H2O. Doklady Akademii Nauk SSSR: 381: 353-355.
  3. 2002Jambor, John L., Grew, Edward S., Roberts, Andrew C. (2002) New mineral names. American Mineralogist, 87. 1509-1513
  4. 2003Mandarino, Joseph A. (2003) New minerals. The Canadian Mineralogist, 41 (3) 803-828 doi:10.2113/gscanmin.41.3.803 DOI: 10.2113/gscanmin.41.3.803
  5. 2010Echigo, T., Kimata, M. (2010) Crystal Chemistry and Genesis of Organic Minerals: a Review of Oxalate and Polycyclic Aromatic Hydrocarbon Minerals. The Canadian Mineralogist, 48 (6) 1329-1357 doi:10.3749/canmin.48.5.1329DOI: 10.3749/canmin.48.5.1329
