Hingganite-(Yb)

BeYb(SiO4)(OH)
IMA status
  • Approved
IMA symbol
Hin-Yb
IMA approved
1982
Also known as
  • Hingganiet-(Yb)
  • IMA1982-041

Where it forms, where it's found

Geological setting

Found on plumbomicrolite and in violet fluorite in amazonite pegmatites. It formed by very late-stage replacement reactions.

Type locality
Ploskaya Mountain
  1. Western Keivy Massif
  2. Keivy Mountains
  3. Lovozersky District
  4. Murmansk Oblast
  5. Russia

67.6333°, 36.7000°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colorless
Streak
White
Cleavage
None Observed
Density
4.83 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 65° · 2V calc = 76°
Refractive index
1.725 – 1.76
Surface relief
High
Principal indices
nα 1.725 · nβ 1.738 · nγ 1.76
Dispersion
r > v weak
Extinction
Z ∧ c = 23°, X ∧ 20°, plane of optic axis (010).
Michel-Lévy diagramhighlighted lineδ = 0.0350
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]350 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation350 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 9.888(5) Å · b = 7.607(3) Å · c = 4.740(2) Å
Ratio a:b:c
1 : 0.769 : 0.479
Z
4
Type-locality form

Acicular crystals, to 2 mm, in spherical aggregates.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
70YbYtterbiumYtterbium1173.045173.045
59.44%
8OOxygenOxygen515.99979.995
27.47%
14SiSiliconSilicon128.08528.085
9.65%
4BeBerylliumBeryllium19.0129.012
3.09%
1HHydrogenHydrogen11.0081.008
0.35%
Total291.145100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hingganiet-(Yb)
  • IMA1982-041

In other languages

German
Hingganit-(Yb) · IMA1982-041
Italian
Hingganite- · Hingganite-(Yb)

Classification

Strunz
10th ed.

9.AJ.20

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AJNesosilicates with BO3 triangles and/or B[4], Be[4] tetrahedra, cornersharing with SiO4Group
  • 9.AJ.20Hingganite-(Yb)Species
Dana
8th ed.

54.02.1a.04

  • 54Nesosilicates Borosilicates and Some BeryllosilicatesClass
  • 54.02Borosilicates and Some Beryllosilicates with B in [4] coordinationType
  • 54.02.1a— unnamed intermediate level —Group
  • 54.02.1a.04Hingganite-(Yb)Species
CIM

14.3.13

  • 14Silicates not Containing AluminumClass
  • 14.3Silicates of BeGroup
  • 14.3.13Hingganite-(Yb)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. Soviet Physics – Crystallography: 28(3): 269-271.
  2. 1983Voloshin, A.V., Pakhomovskii, Y.A., Men'shikov, Y.P., Povarennykh, A.S., Matvinenko, E.N. and Yakubovich, O.V. (1983) Hingganite-(Yb), a new mineral from amazonite pegmatites of the Kola Peninsula. Doklady Acad. Nauk SSSR, 270, 1188-1192. (in Russian)
  3. 1984Dunn, Pete J., Fleischer, Michael, Francis, Carl A., Langley, Richard H., Kissin, Stephen A., Shigley, Hames E., Vanko, David A., Zilczer, Janet A. (1984) New mineral names. American Mineralogist, 69 (7-8) 810-815
  4. 2001(2001) Hingganite-(Yb). Handbook of Mineralogy. Mineralogical Society of America
  5. 2017Bačík, Peter, Miyawaki, Ritsuro, Atencio, Daniel, Cámara, Fernando, Fridrichová, Jana (2017) Nomenclature of the gadolinite supergroup. European Journal of Mineralogy, 29 (6) 1067-1082 doi:10.1127/ejm/2017/0029-2659DOI: 10.1127/ejm/2017/0029-2659
