Gadolinite-(Y)

Y2Fe2+Be2O2(SiO4)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Gad-Y
Also known as
  • Gadoliniet-(Y)
  • Schwarzer Zeolith
  • Ytterbit
  • +6 more

Where it forms, where it's found

Geological setting

Granites and alkalic granitic pegmatites

Type locality
Ytterby
  1. Resarö
  2. Vaxholm
  3. Stockholm County
  4. Sweden

59.4267°, 18.3533°

176recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789106.5 – 7/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous · greasy
Transparency
Opaque
Colour
Black · greenish-black · brown
Streak
Grayish green
Tenacity
brittle
Fracture
Splintery · Conchoidal
Density
4.36 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 85°
Refractive index
1.77 – 1.82
Surface relief
High
Principal indices
nα 1.77 · nβ 1.79 · nγ 1.82
Dispersion
r > v distinct
Michel-Lévy diagramhighlighted lineδ = 0.0500
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]500 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation500 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 10.000(2) Å · b = 7.565(2) Å · c = 4.768(1) Å
Cell angles
β = 90.31(2) °
Ratio a:b:c
1 : 0.757 : 0.477
Z
2
Morphology

Prismatic, massive

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
39YYttriumYttrium288.906177.812
38.01%
8OOxygenOxygen1015.999159.990
34.20%
14SiSiliconSilicon228.08556.170
12.00%
26FeIronIron155.84555.845
11.94%
4BeBerylliumBeryllium29.01218.024
3.85%
Total467.841100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Gadoliniet-(Y)
  • Schwarzer Zeolith
  • Ytterbit
  • Ytterbita
  • Ytterbite
  • Yttersten
  • Yttrit
  • Yttrita
  • Yttrite

In other languages

German
Gadolinit-(Y)
Italian
Gadolinite- · gadolinite-(Y)

Classification

Strunz
10th ed.

9.AJ.20

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AJNesosilicates with BO3 triangles and/or B[4], Be[4] tetrahedra, cornersharing with SiO4Group
  • 9.AJ.20Gadolinite-(Y)Species
Dana
8th ed.

54.02.1b.03

  • 54Nesosilicates Borosilicates and Some BeryllosilicatesClass
  • 54.02Borosilicates and Some Beryllosilicates with B in [4] coordinationType
  • 54.02.1b— unnamed intermediate level —Group
  • 54.02.1b.03Gadolinite-(Y)Species
CIM

14.3.23

  • 14Silicates not Containing AluminumClass
  • 14.3Silicates of BeGroup
  • 14.3.23Gadolinite-(Y)Species

Group, growth & confusion

In the same group
6 members
Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1788Geijer (1788) Vom Hrn Berm Geijer in Stochkholm. Chemische Annalen [Crell's Annalen] für die Freunde der Naturlehre, Arzneygelahrtheit, Haushaltungskunst und Manufacturen. Erster Band 1788 [First Volume], p. 229-230. [First description]
  2. 1802Klaproth, M. H. (1802) LXXVI. Chemische Untersuchung des Gadolinits. In Beiträge zur chemischen Kenntniss der Mineralkörper Vol. 3. Rottmann. p.52-79.
  3. 1805Jameson, R. (1805) Gadolinite. System of Mineralogy II, Bell and Bradfute (Edinburgh, U.K.): 570-572.
  4. 1890Petersson, W. (1890) Studier öfver gadolinit. Geologiska Föreningen i Stockholm Förhandlingar: 12: 275-347.
  5. 1959Pavlov, P.V., Belov, N.V. (1959) The structures of herderite, datolite, and gadolinite determined by direct methods. Soviet Physics - Crystallography: 4: 300-314.
