Hydrodelhayelite

KCa2(Si7Al)O17(OH)2 · 6H2O
IMA status
  • Approved
IMA symbol
Hdhy
Discovered
1979
Also known as
  • Hydrodelhayeliet
  • Hydrodelhayelit
  • Hydrodelhayelita
  • +1 more

Where it forms, where it's found

Geological setting

Supergene zone of an ijolite-urtite pegmatite in an alkaline massif

Type locality
Apatitovyi Tsirk
  1. Rasvumchorr Mine
  2. Rasvumchorr Mt
  3. Murmansk Oblast
  4. Russia
2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Grayish-white
Cleavage
Perfect

(010) perfect, (100) and (001) imperfect

Density
2.168 g/cm³

Optical

Optical type
Biaxial
Refractive index
1.503 – 1.518
Surface relief
Moderate
Principal indices
nα 1.503 · nγ 1.518
Dispersion
relatively strong
Michel-Lévy diagramhighlighted lineδ = 0.0150
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]150 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation150 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 6.6483 Å · b = 23.8462 Å · c = 7.0727 Å
Ratio a:b:c
1 : 3.587 : 1.064
Z
2
Type-locality form

grayish-white alteration product of delhayelite

Comment

Space Group: Pnm21

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2515.999399.975
52.84%
14SiSiliconSilicon728.085196.595
25.97%
20CaCalciumCalcium240.07880.156
10.59%
19KPotassiumPotassium139.09839.098
5.17%
13AlAluminiumAluminium126.98226.982
3.57%
1HHydrogenHydrogen141.00814.112
1.86%
Total756.918100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Fe
  • Mn
  • Mg
  • Sr
  • Na
  • Cl

Synonyms

  • Hydrodelhayeliet
  • Hydrodelhayelit
  • Hydrodelhayelita
  • IMA1979-023

In other languages

German
Hydrodelhayelith · IMA 1979-023
Italian
Hydrodelhayelite · idrodelhayelite

Classification

Strunz
10th ed.

9.EB.10

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EBDouble nets with 4- and 6-membered ringsGroup
  • 9.EB.10HydrodelhayeliteSpecies
Dana
8th ed.

72.05.01.05

  • 72Phyllosilicates Two-dimensional Infinite Sheets with Other Than Six-membered RingsClass
  • 72.05Two-Dimensional Infinite Sheets with Other Than Six-Membered Rings with corrugated and complex layersType
  • 72.05.01Rhodesite groupGroup
  • 72.05.01.05HydrodelhayeliteSpecies
CIM

17.10.10

  • 17Silicates Containing other AnionsClass
  • 17.10Silicates with sulphate, molybdate or tungstateGroup
  • 17.10.10HydrodelhayeliteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1979Dorfman, M.D., Chiragov, M.I. (1979) Hydrodelhayelite, a product of supergene alteration of delhayelite. Novye dannye o mineralakh. Nauka, SSSR (New Data on Minerals of the USSR): 28: 172-175.
  2. 1987Hawthorne, Frank C., Jambor, John L., Bladh, Kenneth W., Burke, Ernst A. J., Grice, Joel D., Phillips, Don, Roberts, Andrew C., Schedler, Robert A., E., James (1987) New mineral names. American Mineralogist, 72 (9-10) 1023-1028
  3. 2001(2001) Hydrodelhayelite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2009Pekov, I. V., Zubkova, N. V., Chukanov, N. V., Sharygin, V. V., Pushcharovsky, D. Yu. (2009) Crystal chemistry of delhayelite and hydrodelhayelite. Doklady Earth Sciences, 428 (1) 1216-1221 doi:10.1134/s1028334x09070393DOI: 10.1134/s1028334x09070393
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Hydrodelhayelite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/hydrodelhayelite-1971},
  note      = {Accessed 2026-05-11}
}
