Melansonite

Na◻KZrSi8O19 · 5H2O
IMA status
  • Approved
IMA symbol
Mso
Also known as
  • IMA2018-168
  • Melansoniet

Where it forms, where it's found

Geological setting

highly alkaline agpaitic rock zone at the contact between a marble xenolith and the host nepheline syenite

Type locality
Poudrette quarry (De-Mix quarry
  1. Demix quarry
  2. Uni-Mix quarry
  3. Carrière Mont Saint-Hilaire
  4. MSH)
  5. Mont Saint-Hilaire
  6. La Vallée-du-Richelieu RCM
  7. Montérégie
  8. Québec
  9. Canada

45.5628°, -73.1417°

1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
colorless to pale yellow
Streak
white
Tenacity
brittle
Cleavage
Perfect

(100)

Fracture
Irregular/Uneven
Density
2.352 g/cm³

Optical

Optical type
Biaxial · 2V calc = 89.9°
Refractive index
1.536 – 1.538
Surface relief
Moderate
Principal indices
nα 1.536 · nβ 1.537 · nγ 1.538
Pleochroism
Non-pleochroic
Dispersion
none observed
UV response
green fluorescence under short-wave radiation
Michel-Lévy diagramhighlighted lineδ = 0.0020
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]20 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation20 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pmma
Cell parameters
a = 24.063(5) Å · b = 6.982(1) Å · c = 6.526(1) Å
Ratio a:b:c
1 : 0.290 : 0.271
Z
2
Type-locality form

acicular to fibrous

Synonyms

  • IMA2018-168
  • Melansoniet

In other languages

German
IMA 2018-168 · Melansonit
Italian
Melansonite

Classification

Strunz
10th ed.

9.EB.05

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EBDouble nets with 4- and 6-membered ringsGroup
  • 9.EB.05MelansoniteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. doi.org (n.d.) https://doi.org/10.1180/mgm.2019.73;
  2. 2005Ferraris, G.; Gula, A. (2005) Polysomatic Aspects of Microporous Minerals - Heterophyllosilicates, Palysepioles and Rhodesite-Related Structures. Reviews in Mineralogy and Geochemistry, 57 (1). 69-104 doi:10.2138/rmg.2005.57.3 DOI: 10.2138/rmg.2005.57.3
  3. 2009Cadoni, Marcella, Ferraris, Giovanni (2009) Two new members of the rhodesite mero-plesiotype series close to delhayelite and hydrodelhayelite: synthesis and crystal structure. European Journal of Mineralogy, 21 (2) 485-493 doi:10.1127/0935-1221/2009/0021-1918DOI: 10.1127/0935-1221/2009/0021-1918
  4. 2019Pekov, I. V., Zubkova, N. V., Agakhanov, A. A., Belakovskiy, D. I., Vigasina, M. F., Yapaskurt, V. O., Britvin, S. N., Turchkova, A. G., Sidorov, E. G., Pushcharovsky, D. Y. (2019) CNMNC Newsletter No. 52, New minerals and nomenclature modifications approved in 2019. Mineralogical Magazine, 83 (6) 887-893 doi:10.1180/mgm.2019.73DOI: 10.1180/mgm.2019.73
  5. 2022(2022) Melansonite. Handbook of Mineralogy. Mineralogical Society of America
