Hydrotalcite

Mg6Al2CO3(OH)16(H2O)4
IMA status
  • Approved
  • Grandfathered
IMA symbol
Htc
Discovered
1842
Also known as
  • Hydrotalcit
  • Hydrotalcita
  • Völcknerit
  • +8 more

Where it forms, where it's found

Geological setting

A serpentine-magnesite body

Type locality
Dypingdal serpentine-magnesite deposit
  1. Snarum
  2. Modum
  3. Buskerud
  4. Norway

60.0646°, 9.8759°

84recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Pearly
Transparency
Transparent
Colour
White · brownish
Streak
White
Cleavage
Perfect

(0001)

Density
2.03 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.495 – 1.531
Surface relief
Moderate
Principal indices
nω 1.511 – 1.531 · nε 1.495 – 1.529
Michel-Lévy diagramhighlighted lineδ = 0.0090
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]90 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation90 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#99
Cell parameters
a = 3.07 Å · c = 23.23 Å
Morphology

Massive, with a foliated or contorted lamellar structure on (0001). Indistinct plates; lamellar-fibrous.

Type-locality form

As contorted, lamellar-to-fibrous white masses of waxy or pearly lustre.

Comment

Z = 3/8

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2315.999367.977
60.93%
12MgMagnesiumMagnesium624.305145.830
24.14%
13AlAluminiumAluminium226.98253.964
8.93%
1HHydrogenHydrogen241.00824.192
4.01%
6CCarbonCarbon112.01112.011
1.99%
Total603.974100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Hydrotalcit
  • Hydrotalcita
  • Völcknerit
  • Völcknerita
  • Völcknerite
  • Volkermit
  • Volkermita
  • Volkermite
  • Völkernit
  • Völkernita
  • Völkernite

In other languages

French
Hydrotalcite
German
Hydrotalcit · Hydrotalkit · Talcid · Völknerit
Spanish
Hidrotalcita · Hidrotalquita · Hydrotalcita · Völcknerita · Volkermita · Völkernita
Italian
idrotalcite
Japanese
ダイアルミネート · ダイバッファーHT · ハイドロタルク石 · ハイドロタルサイト · ヒドロタルサイト · ヒドロタルシト · 合成ヒドロタルサイド
Chinese
水滑石

Classification

Strunz
10th ed.

5.DA.50

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DAWith medium-sized cationsGroup
  • 5.DA.50HydrotalciteSpecies
Dana
8th ed.

16b.06.02.01

  • 16bHydrated Carbonates Containing Hydroxyl or HalogenClass
  • 16b.06AmBn(XO3)pZqxH2O & with (m+n):p = 8:1Type
  • 16b.06.02Sjorgrenite-Hydrotalcite Group (Hydrotalcite Subgroup:Rhombohedral)Group
  • 16b.06.02.01HydrotalciteSpecies
CIM

11.7.4

  • 11CarbonatesClass
  • 11.7Carbonates of AlGroup
  • 11.7.4HydrotalciteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. Processi verbali della Società Toscana di scienze naturali in Pisa: 24: 92-105.
  2. Bulletin de la Société française de Minéralogie: 67: 409-419.
  3. 1842Hochstetter, Carl (1842) Untersuchung über die Zusammensetzung einiger Mineralien [Investigation into the composition of some minerals]. Journal für Praktische Chemie [1) Augit], 27 (1) 375-376 doi:10.1002/prac.18420270156DOI: 10.1002/prac.18420270156
  4. 1920Foshag, William F. (1920) The chemical composition of hydrotalcite and the hydrotalcite group of minerals. Proceedings of the United States National Museum, 58 (2329). 147-153 doi:10.5479/si.00963801.2329.147DOI: 10.5479/si.00963801.2329.147
  5. 1941Frondel, Clifford (1941) Constitution and polymorphism of the pyroaurite and sjögrenite groups. American Mineralogist, 26 (5) 295-315
