Stichtite

Mg6Cr2(CO3)(OH)16 · 4H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Stt
Discovered
1910
Also known as
  • Chrom-Brugnatellite
  • Stichtiet

Where it forms, where it's found

Geological setting

Serpentinites

Highly altered serpentinites and chromitites.

Type locality
Stichtite Hill
  1. Dundas mineral field
  2. Zeehan mining district
  3. West Coast municipality
  4. Tasmania
  5. Australia

-41.8844°, 145.4348°

47recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5 – 2/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Waxy
Transparency
Transparent
Colour
Rose-pink to purple
Streak
White to light lilac
Tenacity
flexible
Cleavage
Perfect

(0001)

Density
2.16 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.516 – 1.542
Surface relief
Moderate
Principal indices
nω 1.516 · nε 1.542
Pleochroism
Weak

O = dark rose-pink to lilac E = light rose-pink to lilac

Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 6.19 Å · c = 46.47 Å
Morphology

Massive. Matted or contorted aggregates of plates or fibers. Cross-fiber veinlets. Micaceous scales.

Type-locality form

Irregularly-shaped masses veins and blebs in serpentine.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2315.999367.977
56.26%
12MgMagnesiumMagnesium624.305145.830
22.30%
24CrChromiumChromium251.996103.992
15.90%
1HHydrogenHydrogen241.00824.192
3.70%
6CCarbonCarbon112.01112.011
1.84%
Total654.002100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe

Synonyms

  • Chrom-Brugnatellite
  • Stichtiet

In other languages

French
Bouazzerite · Chrom-Brugnatellite · Stichtite
German
Stichtit
Spanish
Stichtita
Italian
stichtite

Classification

Strunz
10th ed.

5.DA.50

  • 5CarbonatesClass
  • 5.DCarbonates with additional anions, with H2ODivision
  • 5.DAWith medium-sized cationsGroup
  • 5.DA.50StichtiteSpecies
Dana
8th ed.

16b.06.02.02

  • 16bHydrated Carbonates Containing Hydroxyl or HalogenClass
  • 16b.06AmBn(XO3)pZqxH2O & with (m+n):p = 8:1Type
  • 16b.06.02Sjorgrenite-Hydrotalcite Group (Hydrotalcite Subgroup:Rhombohedral)Group
  • 16b.06.02.02StichtiteSpecies
CIM

11.11.1

  • 11CarbonatesClass
  • 11.11Carbonates of Cr and UGroup
  • 11.11.1StichtiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. https://www.minerant.org/MMM/S/stichtiet-Dundas.html
  2. 1910Petterd, W.F. (1910) Stichtite (carbonatohydrate of magnesium, chrome and iron). in Catalog of the Minerals of Tasmania 3rd Edition, J. Vail Hobart, 167-169.
  3. 1918Poitevin and Graham (1918) Geological Survey of Canada, Museum Bulletin: 27: 29.
  4. 1920Foshag, William F. (1920) The chemical composition of hydrotalcite and the hydrotalcite group of minerals. Proceedings of the United States National Museum, 58 (2329). 147-153 doi:10.5479/si.00963801.2329.147DOI: 10.5479/si.00963801.2329.147
  5. 1933Read, H. H., Dixon, B. E. (1933) On stichtite from Cunningsburgh, Shetland Islands. Mineralogical Magazine and Journal of the Mineralogical Society, 23 (140) 309-316 doi:10.1180/minmag.1933.023.140.03 DOI: 10.1180/minmag.1933.023.140.03
