Igelströmite

Fe3+(SbPb)O4
IMA status
  • Approved
IMA symbol
Ig
Also known as
  • Igelströmiet
  • IMA2021-035

Where it forms, where it's found

Geological setting

distinct hausmannite–braunite and magnetite–hematite ore bodies are hosted by Palaeoproterozoic (∼ 1.9 Ga) dolomitic marbles.

Type locality
Långban Mine
  1. Långban Ore District
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8554°, 14.2648°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
dark reddish-brown to black
Streak
yellowish brown to dark brown
Tenacity
brittle
Cleavage
Distinct/Good

distinct/good on (110)

Fracture
Irregular/Uneven · Conchoidal
Density
6.33 g/cm³

Optical

Pleochroism
Non-pleochroic
Optical colour
greyish-white in plane-polarized light
Bireflectance
weakly bireflectant
Internal reflections
dark brown to red
Reflectance R%
(16.1, 15.2) 470, (15.1,14.4) 546, (14.9, 14.2) 589, (14.8,14.1) 650
Reflected-light panel
15.2 %anisotropic · dual curve
Specimen sRGB 144, 100, 56
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
weakly bireflectant
Reflected colour
greyish-white in plane-polarized light
Internal reflections
dark brown to red

Crystallography

Crystal system
Tetragonal
Space group
P42/mbc
Cell parameters
a = 8.4856(2) Å · c = 6.0450(3) Å
Z
4
Type-locality form

lenticular crystals forming compact crystal aggregates of rounded appearance, up to 1 mm across

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
46.17%
51SbAntimonyAntimony1121.760121.760
27.13%
8OOxygenOxygen415.99963.996
14.26%
26FeIronIron155.84555.845
12.44%
Total448.801100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Igelströmiet
  • IMA2021-035

In other languages

German
Igelströmit · IMA 2021-035

Classification

Strunz
10th ed.

4.JA.20

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JAArsenites, antimonites, bismuthites; without additional anions, without H2OGroup
  • 4.JA.20IgelströmiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2021Miyawaki, Ritsuro, Hatert, Frédéric, Pasero, Marco, Mills, Stuart J. (2021) Newsletter 62. Mineralogical Magazine, 85 (4) 634-638 doi:10.1180/mgm.2021.62DOI: 10.1180/mgm.2021.62
  2. 2022(2022) Igelströmite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2024Holtstam, Dan; Langhof, Jörgen; Friis, Henrik; Karlsson, Andreas; Erambert, Muriel (2024) Igelströmite, Fe3+(Sb3+Pb2+)O4, and manganoschafarzikite, Mn2+Sb3+2O4, two new members of the newly established minium group, from the Långban Mn–Fe deposit, Värmland, Sweden. European Journal of Mineralogy, 36 (2). 311-322 doi:10.5194/ejm-36-311-2024DOI: 10.5194/ejm-36-311-2024
