Joaquinite-(Ce)

NaBa2Fe2+Ti2Ce2(Si4O12)2O2(OH) · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Jq-Ce
Also known as
  • Joaquiniet-(Ce)

Where it forms, where it's found

Geological setting

In natrolite veins cutting a glaucophane schist inclusion in a serpentinite body.

Type locality
California State Gem Mine
  1. Santa Rita Peak
  2. San Benito County
  3. California
  4. USA

36.3361°, -120.6053°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Honey-yellow to brown
Cleavage
Distinct/Good

(001)

Density
3.89 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 30 – 55°
Refractive index
1.748 – 1.823
Surface relief
High
Principal indices
nα 1.748 – 1.754 · nβ 1.76 – 1.767 · nγ 1.762 – 1.823
Pleochroism
Weak

X = Y = colorless; Z = pale yellow.

Dispersion
r < v marked
Extinction
Parallel. X = a; Y = b; Z = c.
Notes

Absorption: Z > Y > X.

Michel-Lévy diagramhighlighted lineδ = 0.0415
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]415 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation415 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2
Cell parameters
a = 10.516(3) Å · b = 9.686(3) Å · c = 11.833(4) Å
Cell angles
β = 109.67(3) °
Ratio a:b:c
1 : 0.921 : 1.125
Z
2
Morphology

Equant or tabular crystals. Pyramidal with a tiny facet of the base, to flat tabular parallel to the base.

Twinning

On (001), polysynthetic, common.

Type-locality form

Small generally individual crystals or grains rarely over one millimeter in diameter. Generally equant, occasionally slightly tabular. Striated.

Comment

Pseudo-orthorhombic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2815.999447.972
31.88%
58CeCeriumCerium2140.116280.232
19.94%
56BaBariumBarium2137.327274.654
19.55%
14SiSiliconSilicon828.085224.680
15.99%
22TiTitaniumTitanium247.86795.734
6.81%
26FeIronIron155.84555.845
3.97%
11NaSodiumSodium122.99022.990
1.64%
1HHydrogenHydrogen31.0083.024
0.22%
Total1405.131100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Joaquiniet-(Ce)

In other languages

French
Joaquinite · Joaquinite- · Joaquinite-(Ce)
German
Joaquinit-(Ce)
Spanish
Joaquinita- · Joaquinita-(Ce)
Italian
Joaquinite- · Joaquinite-(Ce)

Classification

Strunz
10th ed.

9.CE.25

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.25Joaquinite-(Ce)Species
Dana
8th ed.

60.01.1a.01

  • 60Cyclosilicates Four-membered RingsClass
  • 60.01Four-Membered Rings, as TitanosilicatesType
  • 60.01.1a— unnamed intermediate level —Group
  • 60.01.1a.01Joaquinite-(Ce)Species
CIM

14.9.12

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.12Joaquinite-(Ce)Species

Group, growth & confusion

Literature, links & citation

Citations
  1. 1909Louderback, G.D., Blasdale, W.C. (1909) Benitoite, its paragenesis and mode of occurrence. University of California Publications. Bulletin of the Department of Geology: 5: 331-380.
  2. 1932Palache, Charles, Foshag, W. F. (1932) The chemical nature of joaquinite. American Mineralogist, 17 (7) 308-312
  3. 1967Semenov, E. I., Bukin, V. I., Balashov, Yu. A., Sorensen, and H. (1967) Rare earths in minerals of the joaquinite group. American Mineralogist, 52 (11-12) 1762-1769
  4. 1972Laird, Jo, Albee, Arden L. (1972) Chemical composition and physical, optical, and structural properties of benitoite, neptunite, and joaquinite. American Mineralogist, 57 (1-2) 85-102
  5. 1972Cannillo, E., Mazzi, F., Rossi, G. (1972) The structure type of joaquinite. Tschermaks Mineralogische und Petrographische Mitteilungen: 17: 233-246.
