Strontiojoaquinite

(Na,Fe)2Ba2Sr2Ti2(SiO3)8(O,OH)2 · H2O
IMA status
  • Approved
IMA symbol
Sjq
Discovered
1982
Also known as
  • Strontiojoaquiniet
  • Strontiojoaquinita

Where it forms, where it's found

Geological setting

Metamorphosed basalt, included as a tectonic block within the a serpentine body. The basaltic was subjected to high pressure metamorphism, and to considerable compositional modification by fluids during the emplacement of the peridotite and serpentinization.

Type locality
Mina Numero Uno
  1. Picacho Peak
  2. San Benito County
  3. California
  4. USA

36.4000°, -120.6750°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Green · yellow-green · yellow-brown
Cleavage
Distinct/Good

(001) good

Density
3.68 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 35 – 45° · 2V calc = 42°
Refractive index
1.71 – 1.78
Surface relief
High
Principal indices
nα 1.710 · nβ 1.718 · nγ 1.780
Pleochroism
Weak

X = Y (colorless) < Z (yellow).

Dispersion
r > v strong
Extinction
X:a = 19°; Y = b, Z = c.
Notes

Absorption X = Y < Z

Michel-Lévy diagramhighlighted lineδ = 0.0700
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]700 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation700 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 10.516(6) Å · b = 9.764(5) Å · c = 11.87(1) Å
Cell angles
β = 109.28(8) °
Ratio a:b:c
1 : 0.928 : 1.129
Z
2
Morphology

Steep bipyramids with forms (111) and (110) and truncated with a small basal face (001).

Twinning

Submicroscopic twinning.

Type-locality form

Steep bipyramidal crystals to 1 mm.

Comment

Point Group: 2; m; or 2/m: ; Space Group: P 2; Pm; or P 2/m:

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2915.999463.971
33.24%
56BaBariumBarium2137.327274.654
19.67%
14SiSiliconSilicon828.085224.680
16.10%
38SrStrontiumStrontium287.620175.240
12.55%
26FeIronIron255.845111.690
8.00%
22TiTitaniumTitanium247.86795.734
6.86%
11NaSodiumSodium222.99045.980
3.29%
1HHydrogenHydrogen41.0084.032
0.29%
Total1395.981100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Li

Synonyms

  • Strontiojoaquiniet
  • Strontiojoaquinita

In other languages

German
IMA 1979-080 · Strontiojoaquinit
Italian
Strontiojoaquinite · Stronziojoaquinite

Classification

Strunz
10th ed.

9.CE.25

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.25StrontiojoaquiniteSpecies
Dana
8th ed.

60.01.1a.02

  • 60Cyclosilicates Four-membered RingsClass
  • 60.01Four-Membered Rings, as TitanosilicatesType
  • 60.01.1a— unnamed intermediate level —Group
  • 60.01.1a.02StrontiojoaquiniteSpecies
CIM

14.9.14

  • 14Silicates not Containing AluminumClass
  • 14.9Silicates of TiGroup
  • 14.9.14StrontiojoaquiniteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1982Wise, W. S. (1982) Strontiojoaquinite and bario-orthojoaquinite: two new members of the joaquinite group. American Mineralogist, 67 (7-8) 809-816
  2. 2001(2001) Strontiojoaquinite. Handbook of Mineralogy. Mineralogical Society of America
  3. 2008MASHIMA, Hiroki, AKAI, Junji (2008) Four-layer orthorhombic polytype (4O) in strontio-joaquinite group minerals found in the Ohmi region, central Japan. Journal of Mineralogical and Petrological Sciences, 103 (6) 407-411 doi:10.2465/jmps.071022h DOI: 10.2465/jmps.071022h
