Loveringite

(Ca,Ce,La)(Zr,Fe)(Mg,Fe)2(Ti,Fe,Cr,Al)18O38
IMA status
  • Approved
IMA symbol
Lvg
Discovered
1978
Also known as
  • IMA1977-023
  • Loveringiet

Where it forms, where it's found

Type locality
Jimberlana Intrusion
  1. Norseman
  2. Dundas Shire
  3. Western Australia
  4. Australia

-32.1461°, 121.8110°

13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic · Sub-Metallic
Transparency
Opaque
Colour
Black
Streak
Iron-grey
Density
4.42 g/cm³

Optical

Optical colour
White to grayish white

Crystallography

Crystal system
Trigonal
Space group
#80
Cell parameters
a = 10.337(6) Å · c = 20.677(12) Å
Z
3
Morphology

Anhedral to acicular crystals.

Type-locality form

Isolated crystals which are usually anhedral but occasionally it forms needles. The grain size rarely exceeds 100 x 50 µm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron2155.8451172.745
25.93%
24CrChromiumChromium1851.996935.928
20.69%
22TiTitaniumTitanium1847.867861.606
19.05%
8OOxygenOxygen3815.999607.962
13.44%
13AlAluminiumAluminium1826.982485.676
10.74%
58CeCeriumCerium1140.116140.116
3.10%
57LaLanthanumLanthanum1138.905138.905
3.07%
40ZrZirconiumZirconium191.22491.224
2.02%
12MgMagnesiumMagnesium224.30548.610
1.07%
20CaCalciumCalcium140.07840.078
0.89%
Total4522.850100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1977-023
  • Loveringiet

In other languages

French
loveringite
German
IMA 1977-023 · Loveringit
Italian
loveringite

Classification

Strunz
10th ed.

4.CC.40

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CCWith large and medium-sized cationsGroup
  • 4.CC.40LoveringiteSpecies
Dana
8th ed.

08.05.01.02

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.05AB21O38Type
  • 08.05.01Crichtonite group (ABC18 T2 O38)Group
  • 08.05.01.02LoveringiteSpecies
CIM

7.9.25

  • 7Oxides and HydroxidesClass
  • 7.9Oxides of TiGroup
  • 7.9.25LoveringiteSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1978Gatehouse, Bryan M., Grey, Ian E., Campbell, Ian H., Kelly, Patrick (1978) The crystal structure of loveringite - a new member of the crichtonite group. American Mineralogist, 63 (1-2). 28-36
  2. 1978Campbell, I. H., Kelly, P. R. (1978) The geochemistry of loveringite, a uranium-rare-earth-bearing accessory phase from the Jimberlana Intrusion of Western Australia. Mineralogical Magazine, 42 (322) 187-193 doi:10.1180/minmag.1978.042.322.04 DOI: 10.1180/minmag.1978.042.322.04
  3. 1979Kelly, P.R., Campbell, I.H., Grey I.E., Gatehouse, B.M. (1979) Additional data on loveringite (Ca,REE)(Ti,Fe,Cr)21038 and mohsite discredited. Canadian Mineralogist: 17: 635-638.
  4. 1983Dunn, Pete J., Fleischer, Michael, Burns, Roger G., Pabst, Adolf (1983) New mineral names. American Mineralogist, 68 (3-4) 471-475
  5. 2005(2005) Loveringite. Handbook of Mineralogy. Mineralogical Society of America
