Magnesiopascoite

Ca2MgV5+10O28 · 16H2O
IMA status
  • Approved
IMA symbol
Mpas
IMA approved
2007
Also known as
  • IMA2007-025
  • Magnesiopascoiet

Where it forms, where it's found

Geological setting

a V-U oxide-replacement assemblage developed at the expense of organic material.

Type locality
Blue Cap Mine
  1. La Sal Creek Mining District
  2. San Juan County
  3. Utah
  4. USA

38.3368°, -109.0609°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Orange · yellow or red
Streak
yellow
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
Conchoidal
Density
2.43 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 45° · 2V calc = 42°
Refractive index
1.769 – 1.807
Surface relief
High
Principal indices
nα 1.769 · nβ 1.802 · nγ 1.807
Pleochroism

Y (orange) > X (yellow), Z (yellow)

Dispersion
r < v, crossed
Michel-Lévy diagramhighlighted lineδ = 0.0380
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]380 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation380 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 19.8442(15) Å · b = 9.9353(8) Å · c = 10.7149(8) Å
Cell angles
β = 120.305(1) °
Ratio a:b:c
1 : 0.501 : 0.540
Unit cell volume
1823.9 ų
Z
2
Morphology

crystals vary in aspect from tabular to equant to prismatic. (001) prominent. Other forms include (302), (401), (112), (113), (111), (112), (223), and {33_1)

Twinning

none observed

Type-locality form

parallel stacks of lustrous crystals that vary from tabular to equant to prismatic

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen4415.999703.956
52.14%
23VVanadiumVanadium1050.942509.420
37.73%
20CaCalciumCalcium240.07880.156
5.94%
1HHydrogenHydrogen321.00832.256
2.39%
12MgMagnesiumMagnesium124.30524.305
1.80%
Total1350.093100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2007-025
  • Magnesiopascoiet

In other languages

French
magnesiopascoite
German
IMA 2007-025 · Magnesiopascoit
Spanish
magnesiopascoita
Italian
magnesiopascoite

Classification

Strunz
10th ed.

4.HC.05

  • 4OxidesClass
  • 4.HV[5,6] VanadatesDivision
  • 4.HC[6]-SorovanadatesGroup
  • 4.HC.05MagnesiopascoiteSpecies
Dana
8th ed.

47.03.06.03

  • 47Vanadium OxysaltsClass
  • 47.03Hydrated Normal Vanadium OxysaltsType
  • 47.03.06— unnamed intermediate level —Group
  • 47.03.06.03MagnesiopascoiteSpecies

Group, growth & confusion

In the same group
4 members

Literature, links & citation

Citations
  1. 2008Kampf, A. R., Steele, I. M. (2008) Magnesiopascoite, a new member of the pascoite group: description and crystal structure. The Canadian Mineralogist, 46 (3) 679-686 doi:10.3749/canmin.46.3.679 DOI: 10.3749/canmin.46.3.679
  2. 2011(2011) Magnesiopascoite. Handbook of Mineralogy. Mineralogical Society of America
